7

Technical Specifications

Table 3
includes the technical specifications
INPUTS:
OUTPUTS:
BANDWIDTH:
COMPLIANCE WITH
HDMI STANDARD:
CONTROLS:
INDICATOR LEDs:
POWER CONSUMPTION: 12V DC, 1.4A
OPERATING
TEMPERATURE:
STORAGE
TEMPERATURE:
HUMIDITY:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
OPTIONS:
8

Default Communication Parameters

Table 4
lists the default communication parameters for the VM-114H2C.
RS-232
Protocol 2000
Baud Rate:
Data Bits:
Stop Bits:
Parity:
Command Format:
Example (Output 1 to Input 1):
1 Specifications are subject to change without notice
16
Technical Specifications

Table 3: Technical Specifications of the VM-114H2C

1 HDMI Connector
1 TP on an RJ-45 Connector
2 HDMI Connectors
2 TP on RJ-45 Connectors
Up to 2.25Gbps bandwidth per graphic channel (HDMI), 1.65Gbps bandwid h
per graphic channel (DGKat)
Supports HDMI and HDCP
Input select button, EDID select button, panel lock button, RS-232, local and
remote IR controls
IR communica ion, Power, IN 1 HDMI, IN 2 CAT5, OUTPUT 1, 2, 3 and 4
0° to +40°C (32° to 104°F)
–40° to +70°C (–40° to 158°F)
10% to 90%, RHL non-condensing
21 5cm x 16.3cm x 4.4cm (8.5in x 6.4in x 1.7in) W, D, H
0.9kg (1.98lbs) approx.
Power supply, RC-IR3 infrared remote control transmitter
HDMI/HDMI male-to-male cables, RK-1 19" rack adapter

Table 4: Default Communication Parameters

1
of the VM-114H2C.
9600
8
1
None
HEX
0x01, 0x81, 0x81, 0x81
