  • Page 1 User’s Manual for MIL-S801XX...
  • Page 2 - EN60950 (IEC950) - Product Safety Five-Year Limited Warranty MiLAN Technology warrants to the original consumer or purchaser that each of it’s products, and all components thereof, will be free from defects in material and/or workmanship for a period of five years from the original factory shipment date.

  • Page 3: Table Of Contents

    2. Hardware Description Front Panel MIL-S801XX 9 port switch with SC fiber port MIL-S801XX 9 port switch with SC (Single-mode) fiber port MIL-S801XX 9 port switch with ST fiber port MIL-S801XX 9 port switch with MT-RJ fiber port MIL-S801XX 9 port switch with VF-45 fiber port...

  • Page 4: Introduction

    1. Introduction MiLAN’s MIL-S801XX switch with a fiber port is a compact desktop size switch, which is an ideal solution for many network users. It provides wire-speed, Fast Ethernet switching function that allows high- performance, low-cost connections. Figure 1. The MIL-S801XX The MIL-S801XX nine port switch provides 8 switched auto-sensing 10/100 Mbps RJ-45 Ethernet ports and one 100BASE-FX fiber port.

  • Page 5: Features

    Four Rubber Feet with adhesive pads User’s Manual MIL-S801XX switch Power Cord Rubber Feet Figure 1-2. Package Contents Compare the contents of your switch package with the standard checklist above. If any item is missing or damaged, please contact your sales person. User’s Manual...

  • Page 6: Hardware Description

    There are four types of fiber connectors in multi-mode. These fiber connectors are SC, ST, MT-RJ and VF-45. The single-mode version is only available with SC connectors. MIL-S801XX switch with SC (Single-mode) fiber port Figure 2-2. The Front Panel of the MIL-S801XX switch with SC (single mode) fiber port...

  • Page 7: Mil-S801Xx 9 Port Switch With St Fiber Port

    MIL-S801XX switch with ST fiber port Figure 2-3. The Front Panel of the MIL-S801XX switch with ST fiber port MIL-S801XX switch with MT-RJ fiber port Figure 2-4. The Front Panel of the MIL-S801XX switch with MT-RJ fiber port MIL-S801XX switch with VF-45 fiber port Figure 2-5.
  • Page 8 LED Indicators The following table provides descriptions of the LED statuses and meaning. They provide a real-time indication of systematic operation status. Status Power 100M LNK / ACT Blinks FDX / COL Blinks Table 2-1. The description of LED Indicator Color Description Green Power On...

  • Page 9: Rear Panel

    Figure 2-3. Attaching Rubber Feet to each corner on the bottom of the switch Power On Connect the power cord to the power socket on the rear panel of the switch. The other side of power cord connect to the power outlet. The internal power supply in the switch works with AC in the voltage range 100-240VAC, frequency 50~60Hz.

  • Page 10: Network Application

    3.Network Application This section provides two samples of network topology in which the switch is used. In general, the MIL-S801XX switch is configured for use as a desktop or segment switch. The MIL-S801XX switch networks PCs, workstations, and servers to each other by connecting these devices directly to the switch.

  • Page 11: Segment Application

    Segment Application Any of the RJ-45 ports on the MIL-S801XX switch can connect with other switches or Hubs to interconnect small workgroups to form larger switched networks. You can also use fiber ports to connect switches. The distance between two switches via fiber cable can be up to 2Km or up to 60Km (SC single-mode fiber connector).

  • Page 12: Trouble Shooting

    If the power indicator does turn on when the power cord is plugged in, you may have a problem with power outlet, or power cord. However, if the switch powers off after running for a while check for loose power connections, power losses or surges at power outlet. If you still cannot resolve the problem, contact your local dealer for assistance.

  • Page 13: Technical Specifications

    5.Technical Specifications This section provides the specifications for the MIL-S801XX switch Specifications Standards Compliance IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX/FX Fast Ethernet ANSI/IEEE 802.3 Auto-negotiation Protocol CSMA/CD Max Forwarding Rate and 14,880 pps per Ethernet port, Max Filtering Rate...
  • Page 14 A Division of Digi International...
