8 10/100TX + 1 10/100/1000T/10/100 SFP Combo with
4 PoE Injectors Managed Switch
MIL-SM802GAF
8 10/100TX + 2 Gigabit Copper/SFP Combo with 8
PoE Injectors Managed Switch
MIL-SM8TXAF2GPA

User Manual

Rev.1.00
2007-07-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIL-SM802GAF and is the answer not in the manual?

Questions and answers

Related Manuals for MiLAN MIL-SM802GAF

Summary of Contents for MiLAN MIL-SM802GAF

  • Page 1: User Manual

    8 10/100TX + 1 10/100/1000T/10/100 SFP Combo with 4 PoE Injectors Managed Switch MIL-SM802GAF 8 10/100TX + 2 Gigabit Copper/SFP Combo with 8 PoE Injectors Managed Switch MIL-SM8TXAF2GPA User Manual Rev.1.00 2007-07-13...
  • Page 2 Transition Networks will in no case cover damages arising out of the product being used in a negligent fashion or manner. Trademarks The MiLAN logo and Transition Networks trademarks are registered trademarks of Transition Networks in the United States and/or other countries. To Contact Transition Networks...

  • Page 3: Fcc Warning

    FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Table Of Contents

    Contents FCC Warning ..................i CE Mark Warning................ii Introduction ................1 Features.................... 2 Software Feature ................4 Package Contents................7 Hardware Description ............8 Physical Dimension................8 Front Panel ..................8 LED Indicators ................10 Rear Panel..................12 Desktop Installation................. 13 Attaching Rubber Pads ...................13 Power On..................
  • Page 5 Trunk Commands Set ..................27 VLAN Commands Set ..................29 Spanning Tree Commands Set ...............31 QOS Commands Set..................33 IGMP Commands Set ..................34 Mac / Filter Table Commands Set ..............34 SNMP Commands Set ..................35 Port Mirroring Commands Set .................38 802.1x Commands Set..................38 TFTP Commands Set..................41 SystemLog, SMTP and Event Commands Set..........42 SNTP Commands Set ..................43 X-ring Commands Set ..................45...
  • Page 6 SNTP Configuration ................ 58 IP Security ..................61 User Authentication................. 62 Port Statistics .................. 63 Port Control..................64 Port Trunk ..................65 Port Trunk - Aggregator setting ...............65 Port Trunk - Aggregator Information..............66 Port Trunk - State Activity................67 Port Mirroring .................. 68 Rate Limiting...................
  • Page 7 802.1X/Radius Configuration ................93 System Configuration ..................93 802.1x Per Port Configuration ..............94 Misc Configuration ..................95 MAC Address Table ..................96 Static MAC Address..................96 MAC Filtering ....................97 All MAC Addresses..................98 Power over Ethernet ..............100 Factory Default................101 Save Configuration ............... 102 System Reboot ................102 Troubleshooting..............103 Incorrect connections ..............

  • Page 8: Introduction

    Introduction Power-over-Ethernet (PoE) eliminates the need to run power to other devices on a wired LAN. Using Power-over-Ethernet systems installers needs to run only a single Category 5 Ethernet cable that carries both power and data to each device. This allows for greater flexibility in the location of network devices and significantly decreasing installation costs in many cases.

  • Page 9: Features

    Features System Interface/Performance RJ-45 ports support Auto MDI/MDI-X Function Embedded 4-port or 8-port PoE injector function Store-and-Forward Switching Architecture Back-plane (Switching Fabric): 5.6Gbps (8 10/100TX + 2 Giga Copper/Mini-GBIC Combo model) Back-plane (Switching Fabric): 3.6Gbps (8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo model) 1Mbits Packet Buffer 8K MAC Address Table...
  • Page 10 Spanning Tree Support IEEE802.1d Spanning Tree Support IEEE802.1w Rapid Spanning Tree X-ring X-ring, Dual Homing, and Couple Ring Topology Provide redundant backup feature and the recovery time below 300ms Support 802.1ab LLDP ** Bandwidth Control Ingress Packet Filter and Egress Rate Limit Broadcast/Multicast Packet Filter Control System Event Log System Log Server/Client...

  • Page 11: Software Feature

    Software Feature SNMP v1 SNMP v2c Management SNMP v3 Web/Telnet/Console (CLI)/Menu Driven** Port based VLAN IEEE802.1Q Tag VLAN(256 entries) / VLAN ID(Up VLAN to 4K, VLAN ID can be assigned from 1 to 4094) GVRP (256 Groups) Double Tag VLAN (Q in Q)* Port Trunk with LACP Port Trunk: 4 trunk groups of maximum 4 LACP...
  • Page 12 Supports100 entries of MAC address for static Port Security MAC and another 100 for MAC filter Supports 3 mirroring types: “RX, TX and Both Port Mirror packet” Supports IGMP snooping v1 and v2 IGMP 256 multicast groups IGMP query mode Supports 10 IP addresses that have permission to IP Security access the switch management to prevent...
  • Page 13 Supports System log record and remote system System log log server Supports SMTP Server and 6 email accounts for SMTP receiving event alert Up to 3 Trap stations Cold start, Port link down, Port link up, SNMP Trap authorization failure, PoE status, X-ring topology change DHCP Client DHCP...

  • Page 14: Package Contents

    Package Contents Unpack the contents of the 8 10/100TX + 2 Gigabit copper/Mini-GBIC Combo with 8 PoE Injectors Managed Switch 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo then verify them against the checklist below: with 4 PoE Injectors Managed Switch (1) 8 10/100TX + 2 Gigabit copper/Mini-GBIC Combo with 8 PoE Injectors Managed Switch or (1) 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo with 4 PoE Injectors Managed Switch...

  • Page 15: Hardware Description

    This section mainly describes the hardware of the PoE Injector Managed Switch and gives a physical and functional overview on the certain switch. Physical Dimension (MIL-SM802GAF) 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo with 4 PoE Injectors Managed Switch’s physical dimensions is 217mm(W) x 140mm(D) x 43mm(H).
  • Page 16 RJ-45 Ports: 8 x 10/100 N-way auto-sensing for 10Base-T or 100Base-TX connections. Ports 1 ~ 4 are general 10/100Base-TX Ethernet ports; Ports 5 ~ 8 are for Data in/out and Power out. In general, MDI means connecting to another Hub or Switch while MDIX means connecting to a workstation or PC.

  • Page 17: Led Indicators

    LED Indicators The LED Indicators display real-time information of systematic operation status. The following table provides descriptions of LED status and their meaning. The LED indicators description of 8 10/100TX + 2 Gigabit Copper/Mini-GBIC Combo model (MIL-SM8TXAF2GPA) Status Description Green Power On Power No power inputs...
  • Page 18 Connected to network LK/ACT Blinking Networking is active (MINI GBIC 9, 10) Not connected to network The LED indicators description of 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo model (MIL-SM802GAF) Status Description Green Power On Power No power inputs Green...

  • Page 19: Rear Panel

    The Rear Panel of the 8 10/100TX + 1 10/100/1000/100/1000 SFP Combo with 4 PoE Injectors Managed Switch (MIL-SM802GAF) The 3-pronged power plug and terminal block are located on the rear panel of the 8 10/100TX + 2 Gigabit copper/Mini-GBIC Combo with 8 PoE Injectors Managed Switch as...

  • Page 20: Desktop Installation

    Frequency of 50-60Hz, or work with DC 48V which is the redundant power supply for the switch. The Rear Panel of the 8 10/100TX + 2 Gigabit copper/ MINI GBIC Combo with 8 PoE Injector Managed Switch (MIL-SM8TXAF2GPA) Desktop Installation Set the switch on a sufficiently large flat space with a power outlet nearby.

  • Page 21: Network Application

    Network Application This section provides a few samples of network topology in which the switch is used. In general, the PoE Injector Managed Switch is designed as a segment switch which has large address table (8k MAC addresses) and high performance to deal with interconnecting networking segments.

  • Page 22: Small Workgroup

    Power over Ethernet Switch network application Small Workgroup The PoE Injector Managed Switch can be used as a standalone switch to which personal computers, server, printer server, are directly connected to form a small workgroup.

  • Page 23: Segment Bridge

    Small Workgroup application Segment Bridge For enterprise networks where large data broadcasts are constantly processed, this switch is an ideal solution for department users to connect to the corporate backbone. In the illustration below, two Ethernet switches with PCs, print server, and local server attached, are both connected to the switch.
  • Page 24 Segment Bridge application...

  • Page 25: Console Management

    Console Management Login in the Console Interface When the connection between switch and PC is ready, turn on the PC and run a terminal emulation program or Hyper Terminal and configure its communication parameters to match the following default characteristics of the console port: Baud Rate: 9600 bps Data Bits: 8 Parity: none...

  • Page 26: Cli Management

    Console login screen CLI Management The system supports console management – CLI command. After you login to the system, you will see a command prompt. To enter CLI management interface, enter “enable” command. The following table lists the CLI commands and description.

  • Page 27: Commands Level

    CLI command interface Commands Level Access Exit Modes Prompt About This Mode1 Method Method The user commands available at the user level are a subset of Begin a Enter those available at the User session with switch> logout or privileged level. EXEC your switch.
  • Page 28 EXEC mode. • Display advanced function status • Save configuration Enter the To exit to configure privileged Use this mode to Global command switch EXEC configure parameters Configura that apply to your while in (config)# mode, tion privileged enter exit or switch as a whole.

  • Page 29: Commands Set List

    Commands Set List User EXEC Privileged EXEC Global configuration VLAN database Interface configuration System Commands Set Commands Level Description Example show config Show switch switch>show config configuration show terminal Show console switch#show terminal information write memory Save user switch#write memory configuration into permanent memory (flash rom)
  • Page 30 [Gateway] ip dhcp Enable DHCP client switch(config)#ip dhcp function of switch show ip Show IP information of switch#show ip switch no ip dhcp Disable DHCP client switch(config)#no ip dhcp function of switch reload Halt and perform a cold switch(config)#reload restart default Restore to default switch(config)#default...
  • Page 31 [IP address] clients by port fastEthernet 2 switch(config)#dhcpserver ipbinding 192.168.1.1 show dhcpserver switch#show dhcpserver Show configuration of configuration DHCP server configuration show dhcpserver clients switch#show dhcpserver clients Show client entries of DHCP server show dhcpserver Show IP-Binding switch#show dhcpserver ip-binding information of DHCP ip-binding server...

  • Page 32: Port Commands Set

    Port Commands Set Commands Level Description Example interface fastEthernet Choose the port for switch(config)#interface [Portid] fastEthernet 2 modification. duplex Use the duplex switch(config)#interface [full | half] configuration fastEthernet 2 command to specify switch(config-if)#duplex full the duplex mode of operation for Fast Ethernet.
  • Page 33 bandwidth type Set interface ingress switch(config)#interface broadcast-multicast-floo limit frame type to fastEthernet 2 ded-unicast ‘accept broadcast, switch(config-if)#bandwidth type multicast, and flooded broadcast-multicast-flooded-uni unicast frame’ cast bandwidth type Set interface ingress switch(config)#interface broadcast-multicast limit frame type to fastEthernet 2 ‘accept broadcast and switch(config-if)#bandwidth type multicast frame’...

  • Page 34: Trunk Commands Set

    state Use the state interface switch(config)#interface [Enable | Disable] configuration fastEthernet 2 command to specify switch(config-if)#state Disable the state mode of operation for Ethernet ports. Use the disable form of this command to disable the port. show interface show interface switch(config)#interface configuration configuration status...
  • Page 35 [GroupID] [Port-list] with LACP active. 1 1-4 lacp workp 2 lacp [GroupID] :1~4 workp [Port-list]:Member port switch(config)#aggregator group [Workport] list, This parameter 2 1,4,3 lacp workp 3 could be a port range(ex.1-4) or a port list separate by a comma(ex.2, 3, 6) [Workport]: The amount of work ports, this value could not be...

  • Page 36: Vlan Commands Set

    VLAN Commands Set Commands Level Description Example vlan database Enter VLAN configure switch#vlan database mode Vlanmode To set switch VLAN switch(vlan)#vlanmode portbase [portbase| 802.1q | mode. gvrp] switch(vlan)#vlanmode 802.1q switch(vlan)#vlanmode gvrp no vlan No VLAN Switch(vlan)#no vlan Ported based VLAN configuration vlan port-based Add new port based switch(vlan)#vlan port-based...
  • Page 37 port belong to a trunk group, this command can’t be applied. vlan 8021q port Assign a trunk link for switch(vlan)#vlan 8021q port 3 [PortNumber] VLAN by port, if the trunk-link tag 2,3,6,99 trunk-link tag [TaggedVID List] port belong to a trunk group, this command switch(vlan)#vlan 8021q port 3 can’t be applied.

  • Page 38: Spanning Tree Commands Set

    Spanning Tree Commands Set Commands Level Description Example spanning-tree enable Enable spanning tree switch(config)#spanning-tree enable spanning-tree priority Configure spanning switch(config)#spanning-tree [0~61440] tree priority parameter priority 32767 spanning-tree max-age Use the spanning-tree switch(config)#spanning-tree [seconds] max-age global max-age 15 configuration command to change the interval between messages the spanning tree receives...
  • Page 39 forward-time [seconds] forward-time global forward-time 20 configuration command to set the forwarding-time for the specified spanning-tree instances. The forwarding time determines how long each of the listening learning states last before the port begins forwarding. stp-path-cost Use the spanning-tree switch(config)#interface [1~200000000] cost interface fastEthernet 2...

  • Page 40: Qos Commands Set

    a port priority that is used when two switches tie for position as the root switch. stp-admin-p2p Admin P2P of STP switch(config)#interface [Auto|True|False] priority on this fastEthernet 2 interface. switch(config-if)#stp-admin-p2p Auto stp-admin-edge Admin Edge of STP switch(config)#interface [True|False] priority on this fastEthernet 2 interface.

  • Page 41: Igmp Commands Set

    qos priority cos Configure COS Priority switch(config)#qos priority cos 0 [Priority][lowest|low|mid middle dle|high] Configure TOS Priority switch(config)#qos priority tos 3 qos priority tos high [Priority][lowest|low|mid dle|high] Switch#show qos show qos Displays the information of QoS configuration Disable QoS function switch(config)#no qos no qos IGMP Commands Set Commands...

  • Page 42: Snmp Commands Set

    hwaddr address table of fastEthernet 2 [MAC] interface (static). switch(config-if)#mac-address-tab le static hwaddr 000012345678 mac-address-table filter Configure MAC switch(config)#mac-address-table hwaddr address table(filter) filter hwaddr 000012348678 [MAC] show mac-address-table Show all MAC address switch#show mac-address-table table show mac-address-table Show static MAC switch#show mac-address-table static address table...
  • Page 43 snmp agent-mode Select the agent mode switch(config)#snmp agent-mode [v1v2c|v3|v1v2cv3] of SNMP v1v2cv3 snmp Add SNMP community switch(config)#snmp community-strings string. community-strings public right [Community] right [RO/RW] snmp-server host Configure SNMP switch(config)#snmp-server host [IP address] server host information 192.168.1.50 community public community and community string trap-version v1 [Community-string]...
  • Page 44 match-rule [Exact|Prifix] views [Read View Name] [Write View Name] [Notify View Name] snmpv3 mibview view Configure the mibview switch(config)#snmpv3 mibview [View Name] table of SNMPV3 view V1 type Excluded sub-oid type agent 1.3.6.1 [Excluded|Included] sub-oid [OID] show snmp Show SNMP switch#show snmp configuration no snmp...

  • Page 45: Port Mirroring Commands Set

    [Read View Name] [Write View Name] [Notify View Name] no snmpv3 mibview Remove specified switch(config)#no snmpv3 view mibview table of mibview view V1 type Excluded [View Name] SNMPV3 agent. sub-oid 1.3.6.1 type [Excluded|Included] sub-oid [OID] Port Mirroring Commands Set Commands Level Description Example monitor rx...
  • Page 46 8021x enable Use the 802.1x global switch(config)# 8021x enable configuration command to enable 802.1x protocols. 8021x system radiusip Use the 802.1x system switch(config)# 8021x system [IP address] radius IP global radiusip 192.168.1.1 configuration command to change the radius server IP. 8021x system serverport Use the 802.1x system switch(config)# 8021x system...
  • Page 47 8021x misc quietperiod Use the 802.1x misc switch(config)# 8021x misc [sec.] quiet period global quietperiod 10 configuration command to specify the quiet period value of the switch. 8021x misc txperiod Use the 802.1x misc switch(config)# 8021x misc [sec.] TX period global txperiod 5 configuration command to set the...

  • Page 48: Tftp Commands Set

    [disable | reject | accept | state interface fastethernet 3 authorize] configuration switch(config-if)#8021x portstate command to set the accept state of the selected port. show 8021x Displays a summary of switch>show 8021x the 802.1x properties and also the port sates. no 8021x Disable 802.1x switch(config)#no 8021x...

  • Page 49: Systemlog, Smtp And Event Commands Set

    SystemLog, SMTP and Event Commands Set Commands Level Description Example systemlog ip Set System log server switch(config)# systemlog ip [IP address] IP address. 192.168.1.100 systemlog mode Specified the log mode switch(config)# systemlog mode [client|server|both] both show systemlog Displays system log. Switch>show systemlog show systemlog Show system log client...

  • Page 50: Sntp Commands Set

    event Set X-ring topology switch(config)#event X-ring-topology-change changed event type X-ring-topology-change both [Systemlog|SMTP|Both] event systemlog Set port event for switch(config)#interface [Link-UP|Link-Down|Bot system log fastethernet 3 switch(config-if)#event systemlog both event smtp Set port event for switch(config)#interface [Link-UP|Link-Down|Bot SMTP fastethernet 3 switch(config-if)#event smtp both show event Show event selection switch#show event no event...
  • Page 51 sntp daylight Enable daylight saving switch(config)#sntp daylight time, if SNTP function is inactive, this command can’t be applied. sntp daylight-period Set period of daylight switch(config)# sntp [Start time] [End time] daylight-period 20060101-01:01 saving time, if SNTP function is inactive, 20060202-01-01 this command can’t be applied.

  • Page 52: X-Ring Commands Set

    no sntp daylight Disable daylight saving switch(config)#no sntp daylight time X-ring Commands Set Commands Level Description Example Xring enable Enable X-ring switch(config)#Xring enable Xring master Enable ring master switch(config)#Xring master Xring couplering Enable couple ring switch(config)#Xring couplering Xring dualhoming Enable dual homing switch(config)#Xring dualhoming Xring ringport Configure 1st/2nd...

  • Page 53: Web-Based Management

    Web-Based Management This section introduces the configuration and functions of the Web-Based management. About Web-based Management On the CPU board of the switch there is an embedded HTML web site residing in flash memory, which offers advanced management features and allow users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 54: System Information

    Key in “http://” + “IP Address” of the Switch, and then press “Enter” Login screen will appear right after Key in the user name and password. The default user name and password is “root” Click “Enter” or” OK”, then the home screen of the Web-based management appears right after Note: The web interface features shown below are introduced by the screen displays of 8 10/100 TX + 2 10/100/1000T/Mini-GBIC Combo (MIL-SM8TXAF2GPA)

  • Page 55: Ip Configuration

    System Location: Assign the switch physical location (The maximum length is 64 bytes) System Description: Displays the description of switch(Read only cannot be modified) Firmware Version: Displays the switch’s firmware version Kernel Version: Displays the kernel software version MAC Address: Displays the unique hardware address assigned by manufacturer (default) And than, click Apply...

  • Page 56: Dhcp Configuration

    he Internet IP address are easy to be remembered. Because t is based on ; every domain name DNS service time you use a , therefore, a must translate the name domain name into the corresponding IP address. For example, the www.net.com might translate to 192.168.1.1 DNS2: The backup for DNS1.

  • Page 57: Dhcp Server Configuration

    DHCP Server Configuration The system provides the DHCP server function. Enable the DHCP server function, the switch system will be a DHCP server. DHCP Server: Enable or Disable the DHCP Server function. Enable—the switch will be the DHCP server on your local network Low IP Address: The dynamic IP range.

  • Page 58: Dhcp Client Entries

    DHCP Client Entries When the DHCP server function is active, the system will collect the DHCP client information and display it here. DHCP Client Entries interface Port and IP Bindings Assign the dynamic IP address to the port. When the device is connecting to the port and asks for IP assigning, the system will assign the IP address that has been assigned before to the connected device.

  • Page 59: Tftp - Update Firmware

    Port and IP Bindings interface TFTP - Update Firmware It provides the functions that allow user to update the switch firmware. Before updating, make sure the TFTP server is ready and the firmware image is on the TFTP server. TFTP Server IP Address: Key in the TFTP server IP Firmware File Name: The name of firmware image And then, click Apply...

  • Page 60: Tftp - Restore Configuration

    TFTP - Restore Configuration Restore EEPROM value from TFTP server TFTP Server IP Address: Key in the TFTP server IP Restore File Name: Key in the restore file image name And then, click Apply Restore Configuration interface TFTP - Backup Configuration Save current EEPROM value from the switch to TFTP server, then go to the TFTP restore configuration page to restore the EEPROM value.

  • Page 61: System Event Log Configuration

    System Event Log Configuration Configure the system event mode, which you want to collect, and system log server IP. System Log Client Mode: Select the system log mode – client only, server only, or both S/C System Log Server IP Address: Assign the system log server IP Click Reload to refresh the events log...

  • Page 62: System Event Log - Smtp Configuration

    System Event Log - SMTP Configuration You can set up the mail server IP, mail account, account password, and forwarded email account for receiving the event alert. Email Alert: enable or disable the email alert function. SMTP Server IP: set up the mail server IP address (when Email Alert enabled, this function will then be available).

  • Page 63: System Event Log - Event Configuration

    SMTP Configuration interface System Event Log - Event Configuration Select the system log and SMTP events. When selected events occur, the system will result the log information. Also, per port log and SMTP events can be selected. System event selection: 4 selections – Device cold start, Device warm start, SNMP Authentication Failure, and X - ring topology change.
  • Page 64 produce a log event X-Ring topology change: When the X-ring topology has changed, the system will produce a log event And then, click Apply Event Configuration interface Port event selection: Select the per port events and per port SMTP events. It has 3 selections –...

  • Page 65: Sntp Configuration

    Link UP & Link Down: The system will result a log message when port connection is up and down SNTP Configuration You can configure the SNTP (Simple Network Time Protocol) settings. The SNTP allows you to synchronize switch clocks in the Internet. SNTP Client: enable or disable SNTP function to get the time from the SNTP server.
  • Page 66 PDT - Pacific Daylight PST - Pacific Standard -8 hours 4 am ADT - Alaskan Daylight ALA - Alaskan Standard -9 hours 3 am HAW - Hawaiian -10 hours 2 am Standard Nome, Alaska -11 hours 1 am CET - Central European FWT - French Winter MET - Middle European +1 hour...
  • Page 67 Standard GST Guam Standard, USSR Zone 9 IDLE - International Date Line NZST - New Zealand +12 hours Midnight Standard NZT - New Zealand SNTP Sever URL: set the SNTP server IP address. Daylight Saving Period: set up the Daylight Saving beginning time and Daylight Saving ending time.

  • Page 68: Ip Security

    IP Security IP security function allows user to assign 10 specific IP addresses that have permission to access the switch through the web browser for the securing switch management. IP Security Mode: when this option is in Enable mode, the Enable HTTP Server and Enable Telnet Server check boxes will then be available.

  • Page 69: User Authentication

    IP Security interface User Authentication You can change login user name and password for the management security issue User name: Key in the new user name (The default is ‘root’) Password: Key in the new password (The default is ‘root’) Confirm password: Re-type the new password And then, click Apply...

  • Page 70: Port Statistics

    Port Statistics The following information provides the current port statistic information. Port: The port number. Type: Displays the current speed of connection to the port. Link: The status of linking—‘Up’ or ‘Down’. State: It’s set by Port Control. When the state is disabled, the port will not transmit or receive any packet.

  • Page 71: Port Control

    Port Control In Port control, you can view every port status that depends on user setting and the negotiation result. Port: select the port that you want to configure. State: Current port status. The port can be set to disable or enable mode. If the port setting is disable then will not receive or transmit any packet.

  • Page 72: Port Trunk

    Port Trunk The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner.

  • Page 73: Port Trunk - Aggregator Information

    Delete button to delete Trunk Group. Select the Group ID and click Delete button. Port Trunk—Aggregator Setting interface Port Trunk - Aggregator Information When you have setup the aggregator setting with LACP disabled, you will see the local static trunk group information here.

  • Page 74: Port Trunk - State Activity

    Port Trunk – Aggregator Information interface Port Trunk - State Activity When you had setup the LACP aggregator, you can configure port state activity. You can mark or un-mark the port. When you mark the port and click button the port Apply state activity will change to Active.

  • Page 75: Port Mirroring

    Port Trunk – State Activity interface Port Mirroring The Port mirroring is a method for monitor traffic in switched networks. Traffic through ports can be monitored via one specific port. That means traffic goes in or out monitored (source) ports will be duplicated into mirror (destination) port. Destination Port: You can select one port to be the destination (mirror) port for monitoring both RX and TX traffic which come from source port.

  • Page 76: Rate Limiting

    Port Trunk – Port Mirroring interface Rate Limiting You can set up every port’s bandwidth rate and frame limitation type. Ingress Limit Frame type: Select the frame type you want to filter. The frame types have 4 options for selecting: All, Broadcast/Multicast/Flooded Unicast, Broadcast/Multicast and Broadcast only.

  • Page 77: Vlan Configuration

    Rate Limiting interface All the ports support port ingress and egress rate control. For example, assume port 1 is 10Mbps, users can set it’s effective egress rate as 1Mbps, ingress rate as 500Kbps. The switch performs the ingress rate by packet counter to meet the specified rate Ingress: Enter the port effective ingress rate (The default value is ‘0’) Egress: Enter the port effective egress rate (The default value is ‘0’)

  • Page 78: Vlan Configuration - Port-Based Vlan

    However, all the network devices are still plugged into the same switch physically. The switch supports port-based and 802.1Q (tagged-based) VLAN. The default configuration of VLAN operation mode is ‘Disable’. VLAN Configuration interface VLAN configuration - Port-based VLAN Packets can go among only members of the same VLAN group. Note all unselected ports are treated as belonging to another single VLAN.
  • Page 79 VLAN – Port Based interface Click to add a new VLAN group (The maximum VLAN group is up to 256 VLAN groups) Entering the VLAN name, group ID and grouping the members of VLAN group And then, click Apply...
  • Page 80 VLAN—Port Based Add interface You will see the VLAN displays. Delete button to delete unwanted VLAN. Edit button to modify existing VLAN group. Note Remember to execute the ‘Save Configuration’ action, otherwise the new configuration will lose when switch power off.

  • Page 81: 802.1Q Vlan

    802.1Q VLAN Tagged-based VLAN is an IEEE 802.1Q specification standard. Therefore, it is possible to create a VLAN across devices from different switch venders. IEEE 802.1Q VLAN uses a technique to insert a “tag” into the Ethernet frames. Tag contains a VLAN Identifier (VID) that indicates the VLAN numbers.

  • Page 82: 802.1Q Configuration

    802.1q VLAN interface 802.1Q Configuration Enable GVRP Protocol: Mark the check box to enable GVRP protocol. Select the port that you want to configure. Link Type: Access Link: Single switch only, allows user to group ports by setting the same VID to those ports.

  • Page 83: Group Configuration

    Untagged VID: Assign the untagged frame VID. Tagged VID: Assign the tagged frame VID. Click Apply Group Configuration Edit the existing VLAN Group. Select the VLAN group in the table list. Click Apply Group Configuration interface You can Change the VLAN group name and VLAN ID. Click Apply...

  • Page 84: Rapid Spanning Tree

    Group Configuration interface Rapid Spanning Tree The Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol and provides for faster spanning tree convergence after a topology change. The system also supports STP and the system will automatically detect the connected device that is running STP or RSTP protocol.
  • Page 85 Max Age (6-40): The number of seconds a bridge waits without receiving Spanning-tree Protocol configuration messages before attempting reconfiguration. Enter a value between 6 through 40 Hello Time (1-10): The time that controls switch sends out the BPDU packet to check RSTP current status.

  • Page 86: Rstp - Port Configuration

    RSTP - Port Configuration You can configure the path cost and priority of every port. Select the port in Port column. Path Cost: The cost of the path to the other bridge from this transmitting bridge at the specified port. Enter a number 1 through 200000000. Priority: Decide which port should be blocked by priority in LAN.

  • Page 87: Snmp Configuration

    RSTP Port Configuration interface SNMP Configuration Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches and hubs etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.
  • Page 88 String: Fill the name of string. RO: Read only. Enables requests accompanied by this string to display MIB-object information. RW: Read & write. Enables requests accompanied by this string to display MIB-object information and to set MIB objects. Click To remove the community string, select the community string that you have defined and click Remove .

  • Page 89: Trap Configuration

    Trap Configuration A trap manager is a management station that receives traps and the system alerts generated by the switch. If no trap manager is defined, no traps will issue. Create a trap manager by entering the IP address of the station and a community string. To define management stations as trap manager, enter SNMP community strings and selects the SNMP version.
  • Page 90 Configure the SNMP V3 function. Context Table Configure SNMP v3 context table. Assign the context name of context table. Click to add context name. Click Remove to remove unwanted context name. User Profile Configure SNMP v3 user table. User ID: Set up the user name. Authentication Password: Set up the authentication password.
  • Page 91 SNMP V3 configuration interface...
  • Page 92 Group Table Configure SNMP v3 group table. Security Name (User ID): Assign the user name that you have set up in user table. Group Name: Set up the group name. Click to add context name. Click to remove unwanted context name. Remove Access Table Configure SNMP v3 access table.

  • Page 93: Qos Configuration

    Click to add context name. Click to remove unwanted context name. Remove QoS Configuration You can configure QoS policy and priority setting, per port priority setting, COS and TOS setting. QoS Policy and Priority Type Qos Policy: select the QoS policy rule. Using the 8,4,2,1 weight fair queue scheme: The switch will follow 8:4:2:1 rate to process priority queue from High to lowest queue.
  • Page 94 rule. Click Apply QoS Configuration interface...

  • Page 95: Port Base Priority

    Port Base Priority Configure per port priority level. Port: Each port has 4 priority levels – High, Middle, Low, and Lowest. Click Apply COS Configuration Set up the COS priority level. COS priority: Set up the COS priority level 0~7 –High, Middle, Low, Lowest. Click Apply TOS Configuration...
  • Page 96 that support IGMP. Enabling IGMP allows the ports to detect IGMP queries and report packets and manage IP multicast traffic through the switch. IGMP have three fundamental types of message as follows: Message Description A message sent from the querier (IGMP router or switch) Query asking for a response from each host belonging to the multicast group.
  • Page 97 IGMP Configuration interface...

  • Page 98: X-Ring

    X-Ring X-Ring provides a faster redundant recovery than Spanning Tree topology. The action is similar to STP or RSTP, but the algorithms not the same. In the X-Ring topology, every switch should enable X-Ring function and assign two member ports in the ring. Only one switch in the X-Ring group would be set as a master switch that would be blocked, called backup port, and another port is called working port.
  • Page 99 Once its forwarding port fails, the system will automatically upgrade its blocking port to be the forwarding port of the Ring Master switch. Enable Coupling Ring: Enable the coupling ring function. Mark the check box to enable the coupling ring function. Coupling port: Assign the member port which is connected to the other ring group.

  • Page 100: 802.1X/Radius Configuration

    Security In this section, you can configure 802.1x and MAC address table. 802.1X/Radius Configuration 802.1x is an IEEE authentication specification prevents the client from connecting to a wireless access point or wired switch until it provides authority, like the user name and password that are verified by an authentication server.

  • Page 101: 802.1X Per Port Configuration

    802.1x System Configuration interface 802.1x Per Port Configuration You can configure 802.1x authentication state for each port. The State provides Disable, Accept, Reject and Authorize. Hit “Space” key to change the state value. Reject: The specified port is required to be held in the unauthorized state. Accept: The specified port is required to be held in the Authorized state.

  • Page 102: Misc Configuration

    802.1x Per Port Setting interface Misc Configuration Quiet Period: Set the period which the port doesn’t try to acquire a supplicant. TX Period: Set the period the port waits for retransmit next EAPOL PDU during an authentication session. Supplicant Timeout: Set the period of time the switch waits for a supplicant response to an EAP request.

  • Page 103: Mac Address Table

    Click Apply 802.1x Misc Configuration interface MAC Address Table Use the MAC address table to ensure the port security. Static MAC Address You can add a static MAC address; it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.

  • Page 104: Mac Filtering

    Click If you want to delete the MAC address from filtering table, select the MAC address and click Delete Static MAC Addresses interface MAC Filtering By filtering MAC address, the switch can easily filter pre-configured MAC address and reduce the un-safety. You can add and delete filtering MAC address.

  • Page 105: All Mac Addresses

    MAC Filtering interface MAC Address: Enter the MAC address that you want to filter. Click If you want to delete the MAC address from filtering table, select the MAC address and click Delete All MAC Addresses You can view the port information of the connected device’s MAC address and related devices’...
  • Page 106 All MAC Address interface...

  • Page 107: Power Over Ethernet

    Power over Ethernet This segment shows the Power over Ethernet function. PoE Status Maximum Power Available: Displays the maximum power supply in Watt. Actual Power Consumption: This column shows the real-time total power consumption. Power Source: This column shows the power source which is supplying. Power Source 1 (AC): This column shows the supplying power value of power source 1.

  • Page 108: Factory Default

    certain period (for details, see the IEEE 802.3af specification). Capacitive Detection: If the port and capacitive detection are enabled, the capacitances state reads in the voltage result from the constant current. This is the subtracted from the pre-capacitance voltage to get a charge rate. If this charge rate is within the window of the PD signatures, the device is considered to be discovered.

  • Page 109: Save Configuration

    Factory Default interface Save Configuration Save all configurations that you have made in the system. To ensure the all configuration will be saved. Click to save the all configuration to the flash memory. Save Save Configuration interface System Reboot Reboot the switch in software reset. Click Reboot to reboot the system.

  • Page 110: Troubleshooting

    Troubleshooting This section is intended to help solve the most common problems on the PoE Injector Managed Switch. Incorrect connections The switch port can automatically detect straight or crossover cable when you link switch with other Ethernet device. For the RJ-45 connector should use correct UTP or STP cable, 10/100Mbps port use 2-pairs twisted cable and Gigabit 1000T port use 4 pairs twisted cable.

  • Page 111: Improper Network Topologies

    Improper Network Topologies It is important to make sure that you have a valid network topology. Common topology faults include excessive cable length and too many repeaters (hubs) between end nodes. In addition, you should make sure that your network topology contains no data path loops.

  • Page 112: Technical Specification

    Technical Specification This section provides the specifications of 8 10/100TX + 2 Gigabit copper/ Mini-GBIC Combo with 8 PoE Injectors Managed Switch and the 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo with 4 PoE Injectors Managed Switch. IEEE802.3 10BASE-T Ethernet IEEE802.3u 100BASE-TX IEEE802.3ab 1000Base-T IEEE802.3z Gigabit fiber...
  • Page 113 Full-duplex/Collision ([Orange], 8 10/100TX + 1 10/100/1000T/100/1000 SFP Combo with 4 PoE Injectors Managed Switch) 100Base-T: RJ-45 with auto MDI/MDI-X Port 1~4 (4 PoE Injectors model)/ Port 1~8 (8 PoE Injectors model) Connector support POE injecting function 1000Base-T:RJ-45 with auto MDI/MDI-X Gigabit fiber: Mini-GBIC socket 100M fiber: Mini-GBIC socket Store and forward switch architecture...
  • Page 114 135Watts (8 PoE Injectors model) Ventilation 1 fan Operating 0 ~45 , 5%~95%RH Temperature Storage environment -40 ~70 , 95% RH 8 PoE Injectors model : 270mm(W) x 210mm(D) x 44mm(H) Dimensions 4 PoE Injectors model: 217mm(W) x 140mm(D) x 43mm(H) FCC Class A Safety...

  • Page 115: Appendix

    Appendix Console Port Pin Assignments The DB-9 serial port on the switch is used to connect to the switch for out-of-band console configuration. The console—command line interface can be accessed from a terminal or a PC running a terminal emulation program. The pin assignments used to connect to the serial port are provided in the following tables.

  • Page 116: 100Base-Tx/10Base-T Pin Assignments

    Console Port to 9-Pin DTE Port on PC Switch’s 9-Pin Serial CCITT Signal PC’s DTE Port Port 9-Pin ---------RXD ------------ 2 RXD 3 TxD -----------TXD --------- 3 TXD 2 RxD 5 SGND -----------SGND ---------- 5 SGND 100BASE-TX/10BASE-T Pin Assignments With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data;...
  • Page 117 Pin out of POE Midspan Hub/Switch Signal / Name VCC+ VCC+ VCC- VCC- Pin out of POE Endspan Hub/Switch Signal / Name TX+/VCC+ TX-/VCC+ TX+/VCC- TX-/VCC- Note ‘+’ and ‘-‘ signs represent the polarity of the wires that make up each wire pair. Before you powered PD, please check the RJ-45 connector pin assignment follow IEEE802.3af standard, otherwise you may need change one of the RJ-45 connector pin assignment, which attached with the UTP cable.
  • Page 118 are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable. The table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs. Pin MDI-X Signal Name MDI Signal Name Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-)

This manual is also suitable for:

Mil-sm8txaf2gpa

Table of Contents
