Tally Dascom DT-210/230
5.2 Interfaces
Power Supply interface, USB interface and cash drawer interface are standard interfaces for the
printer.
Serial interface, Parallel interface, Ethernet interface and Wi‐Fi interface are optional interfaces for
the printer.
The interface pin assignment is listed below.
5.2.1 USB interface
USB interface pin assignment
PIN No. Description
1
2
3
4
USB interface connector diagram
5.2.2 Cash Drawer interface
Cash Drawer interface pin assignment
Cash drawer interface supports DC24V, 1A, RJ‐11 6P type socket.
Pin. No. Description
Frame Ground
1
Drawer kick‐out drive signal 1 Output
2
Drawer open/close signal
3
+24V
4
Drawer kick‐out drive signal 2 Output
5
GND
6
Cash Drawer interface connector diagram
VBUS
D‐
D+
GND
‐
Input
‐
‐
Classic wire color
Red
White
Green
Black
Direction
27
