6 COMMUNICATION INTERFACES
Power socket and USB interface are standard interfaces for the printer.
Serial interface, Parallel interface, Ethernet interface, Wi-Fi interface and Cash drawer interface are
optional interfaces for the printer.

6.1 USB Interface

USB interface pin assignment
PIN No. Description
1
2
3
4
USB interface connector diagram

6.2 Cash Drawer Interface

Cash Drawer interface pin assignment
Cash drawer interface supports DC24V, RJ-11 6P type socket.
Pin. No. Description
1 Frame Ground
Drawer kick-out drive signal 1
2
3 Drawer open/close signal
+24V
4
Drawer kick-out drive signal 2
5
GND
6
Cash Drawer interface connector diagram
1 6
SPECIFICATIONS
VBUS
D-
D+
GND
-
Output
Input
-
Output
-
Classic wire color
Red
White
Green
Black
Direction
42
