Missed Calls; Call Time; Call Services - ASCOM d41 User Manual

User Manual
Ascom d41 DECT Handset
2 Select entry to delete.
3 Select "Delete".
4 Select "Yes" to delete the entry from the list.
Delete all Entries from the Call list
1 Press the "More" soft key.
2 Select "Delete all".
3 Select "Yes" to delete all the entries from the list.
9.1.2

Missed Calls

1 Select "Missed calls".
2 Step with the
3 Press "Call" to call back.
As in "Call list" there is a "More" soft key which can be used to view the time/date of the
call, edit the received number, add to contacts, and delete received numbers. See
Call List on page 29 for information about the functionality in the "More" soft key.
Note: If supported by the system, the number's contact name can be displayed in the list.
9.1.3

Call Time

The total time of the previous call and last call is displayed by selecting "Call time".
9.1.4

Call Services

Note: These functions are system dependent. Besides the default Call services functions, it
is possible to define 10 extra system specific call services - with or without automatic
disconnection. The parameters are set up in the Portable Device Manager (PDM), see
Configuration Manual, Ascom d41 DECT Handset, TD 92641GB, and Installation and
Operational Manual, Portable Device Manager (PDM), Windows version, TD 92325GB.
Absence Handling
The reason for being absent and the return time or date can be specified here.
1 Select "Call services".
2 Select "Absence".
3 Select the applicable absence reason in the list. The number of absence reasons (for
example "Lunch", "Meeting", "Trip" etc.) in the list are configured in the PDM.
4 Press "Select".
5 Enter time or date.
6 Press "OK"
The handset sends an absence reason code
will automatically be disconnected after a few seconds.
1.The code is defined when configuring the absence/diversion reason in the PDM/IMS2.
2009-12-15/ Ver. C
and to scroll in the list.
1
to the system by establishing a call. The call
TD 92582GB
9.1.1
30
