Egress Bandwidth For Guest Network - The upload speed through the WAN port for Guest

Network.
Ingress Bandwidth For Guest Network - The download speed through the WAN port for

Guest Network.
Guest Network (2.4G/5G) – Click to enable or disable the Guest Network function here.

Network Name - Enter a value of up to 32 characters. The same Name (SSID) must be

assigned to all wireless devices in your Guest Network.
Wireless Security - You can configure the security of Guest Network here.

Access Time - During this time the wireless stations could accessing the AP.


Note:
The range of bandwidth for Guest Network is calculated according to the setting of Bandwidth
Control on the page "Bandwidth Control->Control Settings".
4.9

DHCP

Figure 4-47 The DHCP menu
There are three submenus under the DHCP menu (shown in Figure 4-47): DHCP Settings,
DHCP Clients List and Address Reservation. Click any of them, and you will be able to
configure the corresponding functions.
4.9.1

DHCP Settings

Choose menu "DHCP → DHCP Settings", you can configure the DHCP Server on the page as
shown in Figure 4-48.The router is set up by default as a DHCP (Dynamic Host Configuration
Protocol) server, which provides the TCP/IP configuration for all the PC(s) that are connected to
the router on the LAN.
Archer C7 AC1750 Wireless Dual Band Gigabit Router
Figure 4-48 DHCP Settings
- 62 -
