4.3

Quick Setup

Please refer to 3.2 Quick Installation
4.4

Network

Figure 4-3 the Network menu
There are three submenus under the Network menu (shown in Figure 4-3): WAN, LAN and MAC
Clone, and IPTV. Click any of them, and you will be able to configure the corresponding function.
4.4.1

WAN

Choose menu "Network → WAN", you can configure the IP parameters of the WAN on the
screen below.
1. If your ISP provides the DHCP service, please choose Dynamic IP type, and the router will
automatically get IP parameters from your ISP. You can see the page as follows (Figure
4-4):
Archer C7 AC1750 Wireless Dual Band Gigabit Router
Guide.
Figure 4-4 WAN – Dynamic IP
