Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 6.
Reference Designator
C1, C2, C9, C11, C12, C16,
C17, C20, C41, C42, C48,
C54, C95, C96, C98, C99,
C102, C103
C3, C4, C5, C6, C7, C8, C10,
C25, C31, C40, C43, C45,
C47, C53, C93, C100, C101
J1
J2
J3
J6
L1, L2, L3, L4
LK1, LK3
LK4, LK5, LK6
LK8, LK9
R1, R2, R3, R4, R5, R6, R7
R8
R15, R16, R17, R18
R45, R46, R47
R48
TP1 to TP7
U2
U3
U6
U8
U11
U28
VOUT, VOUT_BUF, VREF,
VREFN, VREFP
Part Description
Capacitor, 10 μF, 16 V, 10%, Case B
Capacitor, 0603, 0.1 μF, 16 V
3-pin terminal block (5 mm pitch)
2-pin terminal block (5 mm pitch)
120-way connector (0.6 mm pitch)
20-pin (2 × 10) header
Ferrite bead 600 Ω
3-pin SIL header and shorting link
2-pin (0.1" pitch) header and
shorting shunt
4-pin (2 × 2) 0.1" header and
shorting shunt
SMD resistor, 0 Ω
SMD resistor, 1.5 kΩ
SMD resistor, 10 kΩ
Precision resistor, 1 kΩ
Precision resistor, 2 kΩ
Black testpoint
Dual op amp
2
64K I C serial EEPROM
Single op amp, 8-pin
Dual op amp
18-bit, ±1 LSB INL, voltage output DAC
Single op amp, 8-pin
Straight PCB mount SMB jack, 50 Ω
Part Number
TAJB106K016R
B0603R104KCT
CTB5000/3
CTB5000/2
FX8-120S-SV(21)
N/A
74279204
M20-9990345 and M7567-05
M20-9990246 and M7566-05
M20-9983646 and M7566-05
MC 0.063W 0603 0R
MC 0.1W 0805 5% 1K5
MC 0.063W 0603 10k
PCF0805-13-1K-B-T1
PCF0805-13-2K-B-T1
20-2137
AD8676BRZ
24LC64-ISN
AD8675ARZ
AD8676BRZ
AD5781BRUZ
AD8675ARZ
1-1337482-0
Rev. 0 | Page 15 of 16
UG-184
Stock Code
FEC 498737
FEC 9406140
FEC 151790
FEC 151789
FEC 1324660
FEC 1022244 (36 + 36 pin strip)
FEC 1635719
FEC 1022248 and FEC 150410
FEC 1022247 and FEC 150-411
FEC 1022244 and 150-411
(36 pin strip)
FEC 9331662
FEC 9333924
FEC 9331700
FEC 1108863
FEC 1108872
FEC 240-333
AD8676BRZ
FEC 9758070
AD8675ARZ
AD8676BRZ
AD5781BRUZ
AD8675ARZ
FEC 1206013
