Evaluation Board User Guide

EVALUATION BOARD HARDWARE

POWER SUPPLIES

The following external supplies must be provided:
5 V between the V
and DGND inputs for the digital
CC
supply of the AD5781. Alternatively, place Link 1 in
Position A to power the digital circuitry from the USB
port (default).
7.5 V to 16.5 V between the V
positive analog supply of the AD5781.
−2.5 V to −16.5 V between the V
the negative analog supply of the AD5781.
The analog and digital planes are connected at one location,
close to the AD5781. To avoid ground loop problems, it is
recommended not to connect AGND and DGND elsewhere
in the system.
Each supply is decoupled to the relevant ground plane with 10 μF
and 0.1 μF capacitors. Each device supply pin is again decoupled
with a 10 μF and 0.1 μF capacitor pair to the relevant ground plane.

LINK OPTIONS

The link options on the evaluation board should be set for the
required operating setup before using the board. The functions
of the link options are described in Table 5.
Default Link Option Setup
The default link options are listed in Table 1.
Table 1. Default Link Options
Link No.
Option
LK1
A
LK3
A
LK4
Removed
LK5
Removed
LK6
Removed
LK8
A
LK9
C
and AGND inputs for the
DD
and AGND inputs for
SS
Rev. 0 | Page 3 of 16
Connector J6 Pin Descriptions
Table 2. Connector J6 Pin Configuration
9
7
5
10
8
6
Table 3. Connector J6 Pin Descriptions
Pin No.
Description
1
SDO
2
RESET
3
DGND
4
CLR
5
IOVCC
6
LDAC
7
SDIN
8
DGND
9
SCLK
10
SYNC

ON-BOARD CONNECTORS

There are nine connectors on the AD5781 evaluation board
PCB as outlined in Table 4.
Table 4. On-Board Connectors
Connector
Function
J1
Analog power supply connector
J2
Digital power supply connector
J3
SDP board connector
J6
Digital interface pin header connector
VOUT
DAC output connector
VOUT_BUF
Buffered DAC output connector
VREF
5 V voltage reference input connector (+10 V
and −10 V reference voltages are generated
from 5 V input)
VREFN
DAC negative reference input connector
VREFP
DAC positive reference input connector
UG-184
3
1
4
2
