2.2.4 Loudspeaker Amplifier DIP Switches

See
See Table 2-3
DIP Switch Setting
1
2
3
4
DIP Switch Setting
1
2
3
4
a.
power injector in this mode (CyberData part number 010867A).
DIP Switch Setting
2
2
Operations Guide
Figure 2-8 to identify the DIP Switches.
and Table 2-4 for the DIP Switch settings.
Table 2-3. DIP Switch Settings—Low Power—802.3af Compliant (Default)
Description
OFF Sets PoE for 802.3af class.
N/A Not applicable for power setting.
ON Switch mode current set to LOW.
OFF Low gain amplifier setting.
Table 2-4. DIP Switch Settings—High Power—Non-PoE Compliant
Description
ON Sets PoE for 802.3at class.
N/A Not applicable for power setting.
OFF Switch mode current set to HIGH.
ON Force high gain amplifier.
If set to high power, the unit will not power ON with 802.3af compliant switch. You must use a
Description
OFF Manual Vol. The speaker volume is set manually by the analog volume
trimmer.
ON Bypass. Bypasses the manual volume control of the analog volume
trimmer and uses the web page volume settings.
Figure 2-8. DIP Switches
Table 2-5. DIP Switch 2 Settings
930362N
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
a
