7. Pull out the air tube through the wing section.
8. Secure the air retract to the wing.
9. Install the window using the plastic collar.
10. Make the same way for install the second
landing gear.
Machine screw
11.Secure the wing to the fuselage using the
22

INSTALLING THE HORIZONTAL STABILIZER

1. Remove the covering from the fuselage.
23
2. Slide the joiner to the horizontal stabilizer.
Plastic collar
24
3. Attach the stabilizer to the fuselage.
25
6
plastic screws.
Remove the covering
Dihedral brace
LA9
Plastic screw
26
27
28
Dihedral brace
29
