Instruction Manual
5. Secure the retract to the wing.
Screw
6. Install and secure the wheel.
7. Secure the strut to the retract.
8. Lock-up the axle.
Screw
22
Screw
23
Screw
24
25
9. Secure the wooden plate.
INSTALLING THE HORIZONTAL STABILIZER
1. Repeat these step from the installing aileron for
the installing elevator.
2. Remove the covering.
5
PRECEPTOR 90MM
Machine screw
26
C.A glue
Remove the covering
27
28
