Numerical display
8 NO ANSWER
100 RESTRICTION
101 DELAYED
Extended result codes
■
Numerical display
5 CONNECT 1200
10 CONNECT 2400
11 CONNECT 4800
13 CONNECT 7200
12 CONNECT 9600
15 CONNECT 14400
16 CONNECT 19200
17 CONNECT 38400
18 CONNECT 57600
19 CONNECT 115200
20 CONNECT 230400
21 CONNECT 460800
When n=1 is set for the ATV<n> command (nP. 36), result codes are displayed as text (default setting). When set
to n=0, they are displayed as numerical values.
Communication speed is displayed to maintain compatibility with conventional modems connected by RS-232C.
However, since the FOMA terminal is connected to the PC using FOMA USB Cable with Charge Function 02 (sold
separately), the displayed speed will differ from the actual speed of connection.
When [RESTRICTION] (Number: 100) appears, the communication network is congested. Try connecting again later.
Communication protocol result codes
Numerical display
1 PPPoverUD
5 PACKET
Result code display examples
When ATX0 is set
The CONNECT display appears only when connection is completed, regardless of the AT¥V<n> command
(nP. 37) setting.
Text display example:
Numerical display example: ATD*99***1#
When ATX1 is set
When ATX1 and AT¥V0 are set (initial value)
When connection is completed, CONNECT <speed between FOMA terminal and PC> appears in the syntax.
Text display example:
Numerical display example: ATD*99***1#
When ATX1 and AT¥V1 are set
When connection is completed, the information below appears in the syntax.
CONNECT <speed between FOMA terminal and PC> PACKET <host (APN)>/<maximum uplink speed (FOMA
terminal to mobile network base station)>/<maximum downlink speed (mobile network base station to FOMA
terminal)>
Text display example:
Numerical display example: ATD*99***1#
* Dial-up connection may not be processed correctly when ATX1 and AT¥V1 are simultaneously set. Using only
AT¥V0 is recommended.
Text display
Connection completed. The server connection timed out.
Network restricted.
Redial restricted.
Text display
FOMA terminal and PC connected at 1,200 bps.
FOMA terminal and PC connected at 2,400 bps.
FOMA terminal and PC connected at 4,800 bps.
FOMA terminal and PC connected at 7,200 bps.
FOMA terminal and PC connected at 9,600 bps.
FOMA terminal and PC connected at 14,400 bps.
FOMA terminal and PC connected at 19,200 bps.
FOMA terminal and PC connected at 38,400 bps.
FOMA terminal and PC connected at 57,600 bps.
FOMA terminal and PC connected at 115,200 bps.
FOMA terminal and PC connected at 230,400 bps.
FOMA terminal and PC connected at 460,800 bps.
Text display
Connected with 64K data communication
Connected with packet communication
ATD*99***1#
CONNECT
1
ATD*99***1#
CONNECT 460800
1 21
*
ATD*99***1#
CONNECT 460800 PACKET mopera.net/5760/7232
(Indicates terminal connected to mopera.net, at maximum uplink speed of 5,760
kbps and maximum downlink speed of 7,232 kbps)
1 21 5
Meaning
Meaning
Meaning
41
