Command name: +CGEQREQ=[parameter]
■
Overview
Sets QoS (Quality of Service) required of the network when establishing PPP packet communication.
Not stored in FOMA terminal's memory with AT&W commands. Not reset with AT&F or ATZ commands.
Syntax
AT+CGEQREQ=[<cid> [,<Traffic class> [,<Maximum bitrate UL> [,<Maximum bitrate DL> [,,,,<Maximum SDU size>]]]]]o
Parameter description
This setting is assigned to each cid by default value.
<cid>
<Traffic class>
2: interactive (initial setting)
3: background
<Maximum bitrate UL>
<Maximum bitrate DL>
However, even if the values of [Maximum bitrate UL] and [Maximum bitrate DL] are permitted level, they may be
set to the values whose fractions were discarded.
<Maximum SDU size>
When <PDP_type> is PPP : 10 to 1500 or 1502 (initial setting)
When <PDP_type> is IP
<cid> is a number for managing hosts (APNs) used for packet communication, registered in the FOMA terminal.
Execution examples
Setting (1) is set to each cid as initial setting.
(1) Command when requesting connection without setting uplink/downlink speeds (for <cid>=5, Traffic class=2)
AT+CGEQREQ=5
OK
(2) Command when requesting connection at uplink speeds of 5,760 kbps, downlink speeds of 7,232 kbps, and
maximum permitting SDU size 1500 (for <cid>=6, Traffic class=2)
AT+CGEQREQ=6,2,5760,7232,,,,1500
OK
(3) Command when requesting connection without setting uplink speeds of 5,760 kbps or downlink speeds (for
<cid>=7, Traffic class=2)
AT+CGEQREQ=7,2,5760
OK
(4) Command when requesting connection at downlink speeds of 7,232 kbps without setting uplink speeds (for
<cid>=8, Traffic class=2)
AT+CGEQREQ=8,2,,7232
OK
Operation when parameter is abbreviated
AT+CGEQREQ=
Returns all <cid> settings to default settings.
AT+CGEQREQ=<cid>
Returns specified <cid> setting to default setting.
AT+CGEQREQ=?
Displays list of values that can be set.
AT+CGEQREQ?
Displays current settings.

Result codes

Result codes
■
Numerical display
0 OK
1 CONNECT
2 RING
3 NO CARRIER
4 ERROR
6 NO DIALTONE
7 BUSY
: 1 to 10
: 2 or 3
: None (initial setting) or 64 to 5760
: None (initial setting) or 64 to 7232
: 10 to 1500 (initial setting)
Text display
Successfully executed.
Connected to number dialed.
Call detected.
Line disconnected.
Command not accepted.
No dial tone detected.
Detecting busy tone.
Meaning
