XX003
Camera Dome
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements
or that the operation will be entirely error free or perform precisely as described in the documentation. This
system has not been designed to be used in life-critical situations and must not be used for this purpose.
Copyright © 1999 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELE: 516-952-CCTV (2288) FAX: 516-951-CCTV (2288) TOLL FREE: 800-645-9116
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8003-00-00 Section 1 Rev 699
Advertisement
Table of Contents
Related Manuals for Vicon Surveyor 99
Summary of Contents for Vicon Surveyor 99
-
Page 1: Camera Dome
XX003 Camera Dome Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose. -
Page 3: Table Of Contents
Contents INTRODUCTION........................1 SOFTWARE FEATURES .....................3 PROGRAMMING MENUS ....................5 Pan/Tilt Controller ............................5 Camera Controller ............................6 Alarm Handling .............................10 Relay Driver..............................12 Source Titling..............................12 Preset/Tour Handler .............................14 Scheduler/Time of Day..........................15 Language...............................16 Install Defaults ..............................17 Contents • i XX003 Rev 699 Surveyor99 Camera Dome Programming... -
Page 5: Introduction
Introduction This manual details the programming features of the Surveyor99. It is intended to be used in conjunction with XX002, Surveyor99 Installation and Operation manual. Programming is performed with a keypad input device using a simple on-screen menu system. All functions programmed into the Surveyor99 stay resident in the Dome Assembly and do not occupy any external CPU memory. - Page 6 NOTES 2 • Introduction XX003 Rev 699 Surveyor99 Camera Dome Programming...
-
Page 7: Software Features
Software Features Most of the Surveyor99 features are accessed remotely through either a System Console (V1400X-DVC), Keypad (V1300X-RVC rack mount or V1300X-DVC desktop) or a PC using a ProTech software/hardware package (V1400X-PACP PacPro). To program certain features, a numeric preset is either stored or recalled. Preset functions can represent a variety of features. - Page 8 Preset 94 (Enter Dome Menu System) — Many Surveyor99 features are accessed through a series of on- screen menus. These are described in the following programming menu sections and accessed by storing preset 94. A Menu Flow Chart is included at the back of this manual. Recalling preset 94 has no effect. Preset 95 (Auto-Baud Detect Feature) —...
-
Page 9: Programming Menus
Programming Menus V5UVS PROGRAM MENU The Main Programming Menu is the first one seen when entering programming Pan/Tilt Controller mode (store preset 94). Subsequent menus, called sub-menus are accessible Camera Controller from this point. When in programming mode, a function is entered by pressing the Alarm Handling AP (autopan) key. -
Page 10: Camera Controller
PAN/TILT CONTROLLER These menu settings do not affect the camera speed when acquiring a preset target. Presets are solved at the fastest possible speed regardless of the maximum manual speed selected. Default setting for pan speed is 120° per Max. Manual Pan Speed second, while tilt speed is 90°... - Page 11 CAMERA CONTROLLER Peak Iris Level CAMERA CONTROLLER Focus Mode allows the autofocus feature to be toggled on or off (default is on). NTSC However, the most practical way to disable autofocus is to press either of the Focus buttons on the keyboard. This will temporarily disable focus until the camera Focus Mode is zoomed in or out again.
- Page 12 BACKLIGHT COMPENSATION The Backlight Compensation menu allows adjustment of this setting. Backlight NTSC compensation improves the contrast of a silhouetted image when it is overshadowed by a lighting source coming from behind it. This includes cameras in windowed rooms such as lobby areas, where intense sunlight coming through BLC Mode: ENABLED BLC Tuning Value the window renders features on a silhouetted person unrecognizable.
- Page 13 WHITE BALANCE The White Balance allows the user to override the automatic color correction NTSC circuitry in the Surveyor99. To adjust the red and blue gain, white balance mode must first be changed to Manual (default is automatic). In manual mode, select either the Red Gain or Blue Gain menu and adjust that parameter on the sliding MODE: MANUAL RED GAIN...
-
Page 14: Alarm Handling
CAMERA CONTROLLER The Digital Zoom Mode screen allows the digital zoom feature on the Surveyor99 NTSC to be disabled (default setting is enabled). When the Zoom In button is held, the lens magnifies the image to the limit of the 16:1 optical zoom. Releasing the button Digital Zoom Mode and tapping it will enable digital magnification of the image, with each tap ENABLED... - Page 15 ALARM INPUT CONTROLLER The Acknowledge Mode menu determines whether an alarm is acknowledged ACKNOWLEDGE MODE manually by the operator or automatically after a predetermined period of time (up INPUT MODE to 60 seconds). MANUAL MANUAL The next two menus program what happens during an alarm event. Each alarm is MANUAL actually two events, set and reset.
-
Page 16: Relay Driver
The Preset Titles, Sector Titles, and Alarm Titles options are programmed in a similar manner. Each preset has a title that appears on screen after the target is TITLE TEXT VICON SURVEYOR99 acquired and disappears when any key is pressed on the keyboard controller (including operation of the joystick). - Page 17 DISPLAY CONTROLLER The Enable Title Text menu functions similarly to the All Titles option. This allows ENABLE TITLE TEXT the user to individually turn off any of the titling functions, including Camera Title, Camera Title: ENABLED Alarm Titles, Preset Titles, and Sector Titles. Two status titles, AUX Function Alarm Title: ENABLED Status and Lens Status provide on-screen displays of the status of those sub-...
-
Page 18: Preset/Tour Handler
Preset/Tour Handler PRESET/TOUR HANDLER The Preset/Tour Handler function manages the 79 presets, 8 tours and 2 Program Presets autotours resident in the Surveyor99. These features are available to the operator Program Auto Home regardless of the type of control device which controls the Surveyor99. Program Tours Program Auto Tour The first sub-menu in the Preset/Tour Handler allows a choice from several... -
Page 19: Scheduler/Time Of Day
• Call Autotour — This calls an autotour sequence. Once the called PRESET/TOUR HANDLER autotour is completed, control is returned to the calling tour. Configure Auto Tours • Dwell — Inserts a “wait” cycle, from 1 to 60 seconds, between actions. Auto Tour Number: 88 •... -
Page 20: Language
TIME CONTROLS Date Format MM/DD/YY TIME ENTRY 12:MM:SS -------------- 09:03:39 PM DATE ENTRY MM/DD/YY -------------- 09/12/66 PROGRAM TIMED EVENTS Event num: 1 Event type: Unused Pttrn/Nmbr: Time of Day: Schedule: Day of Week: Language V5UVS PROGRAM MENU LANGUAGE SELECT The Language feature allows the selection of one of four languages: English, Spanish, French and German. -
Page 21: Install Defaults
Install Defaults Install Defaults Selecting YES and Finally, the Install Defaults option restores all Surveyor99 settings to their factory pressing AP will reset defaults. This affects all programmed functions. all Surveyor settings to the factory defaults including presets, tours and titles. Continue ? NO. - Page 23 Vicon Industries Inc. Offices Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 516-952-CCTV (2288) 1-800-645-9116 Fax: 516-951-CCTV (2288) Infofax: 1-800-287-1207 Atlanta Office 3070AA Business Park Drive Norcross, Georgia 30071 770-449-0499 1-800-824-8479 Fax: 770-446-8779 Vicon U.K. Brunel Way Fareham, PO15 5TX...
