Summary of Contents for Vicon SVFT-C22

  • Page 1: Camera Dome

    Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation.
  • Page 3 8. Accessories - Do not place the unit on an unstable surface following repair or maintenance to verify proper operation. to avoid falling. Use only Vicon recommended mounting accessories.. 22. ESD Precaution - Take all normal electrostatic discharge 9. Ventilation - Do not block ventilating slots and openings as precautions to avoid component damage during installation and they ensure reliable operation.

  • Page 4: Fcc Notice

    FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.

  • Page 7: Table Of Contents

    Contents INTRODUCTION........................1 How to Use this Manual ..........................3 Accessory Kits..............................4 Unpacking and Inspection..........................4 SurveyorVFT Components ..........................7 Enclosure ..............................7 Camera Drive ............................7 Shroud...............................7 Lower Dome ..............................7 Housing ..............................7 Sunshield..............................7 INSTALLATION ........................9 Quick Installation – In-Ceiling Model......................10 Quick Installation – Indoor Pendant ......................11 Quick Installation –...
  • Page 8 SHIPPING INSTRUCTIONS....................59 REFERENCE ........................60 Coaxial Cable Recommendations ......................60 Twisted-Pair Cable............................61 1.5-inch Pipe Designation ........................... 61 TECHNICAL INFORMATION..................... 63 Camera Specifications........................... 66 VICON STANDARD EQUIPMENT WARRANTY ............... 68 iv • Contents XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 9: Introduction

    23X day/night camera/lens. See Technical Information for camera features. Refer to tables below for specific model numbers and options available. Call your Vicon representative for model availability. All versions use the same firmware for programming and operation. For programming, refer to the SurveyorVFT Programming Manual XX134-4X.
  • Page 10 SurveyorVFT Models Model Number Product Environment/ Camera Mount Optical Zoom/ Lower Code Cable Type Type/Format Type Total Zoom Dome Type SVFT-C22 8701-00 Indoor/Coax Color/NTSC Ceiling ExView 22x/264x Smoked SVFT-C22C 8701-01 Indoor/Coax Color/PAL Ceiling ExView 22x/264x Smoked SVFT-P22 8704-00 Indoor/Coax Color/NTSC...

  • Page 11: How To Use This Manual

    How to Use this Manual This manual was designed to provide the best overall instructions for the installation and operation of the SurveyorVFT Camera Dome. The graphics and terminology used in this manual have been carefully selected to enable a clear and distinct understanding of the SurveyorVFT and its components. This manual has been formatted to present distinct methods of installation for all installers.

  • Page 12: Accessory Kits

    Installation section for details on applying the lubricant. Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to provide suitable delivery. Inspect the cartons upon delivery and, if damage is present, make detailed notes on the carrier’s bill. Then, obtain the carrier agent’s signature and file a damage claim as soon as possible.
  • Page 13 Unpacking the SurveyorVFT In-Ceiling Unpacking the SurveyorVFT Indoor Pendant Introduction • 5 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...
  • Page 14 Unpacking the SurveyorVFT Outdoor Pendant 6 • Introduction XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 15: Surveyorvft Components

    SurveyorVFT Components All SurveyorVFT units are comprised of an Enclosure/Housing, a Camera Drive, a Shroud and a Lower Dome. Figures 1, 2 and 3 show In-Ceiling, Indoor Pendant and Outdoor Pendant models, respectively. Enclosure The enclosure is a metal shell that houses the camera drive for the in- ceiling model.
  • Page 16 Figure 2 SurveyorVFT Indoor Pendant Figure 3 SurveyorVFT Outdoor Pendant 8 • Introduction XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...
  • Page 17 Introduction • 9 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 18: Installation

    Installation Choose the installation type based on the specific unit purchased (In-Ceiling, Indoor or Outdoor Pendant). Quick Installation – In-Ceiling Model 10 • Installation XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 19: Quick Installation - Indoor Pendant

    Quick Installation – Indoor Pendant Installation • 11 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 20: Quick Installation - Outdoor Pendant

    Quick Installation – Outdoor Pendant 12 • Installation XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 21: Detailed Installation

    Detailed Installation These steps provide the most thorough and accurate instructions. In-Ceiling Mount Model This version of SurveyorVFT mounts in the ceiling and rests on the ceiling material occupying the space between the lower ceiling and upper building frame. All mounting hardware is provided. Use of the Provided Scribe A small metal scribe is provided to assist in marking an accurate hole size in a ceiling tile for in-ceiling installations.
  • Page 22 The accessory kit contains the removable screw terminal blocks to be used for all connections in this installation. The ceiling material must provide a surface of suitable strength for the SurveyorVFT weight of 5.1 lb (2.3 kg) on the area of the two flippers. Refer to the Optional Independent Support sub- section for installations requiring additional support.
  • Page 23 Note: There should be minimal wire slack at all connection points. a) Strip approximately 1 inch (25 mm) of cable outer jacket to be terminated in terminal blocks. Then strip approximately 0.25 inches (6 mm) of insulation off of each individual wire. b) Refer to Wiring section and Tables 2A, 2B and 2C to make all connections to terminal blocks TB1 (power), TB2 (alarms), TB3 (relays/control signals) and TB4 (UTP video).
  • Page 24 9. Connect the enclosure’s safety cord clip to the tab in the camera drive to allow the drive to hang from the enclosure. Refer to Figure 7 for location of tab. Insert the clip of the safety cord on the lower dome into the hole in the enclosure.

  • Page 25: Optional Independent Support

    Optional Independent Support If it is necessary to provide independent support for the SurveyorVFT, other than the ceiling material, order the optional In-Ceiling Model Mount Kit SVFT-IC-KT. It consists of a pre-assembled set of mounting rails and folding ring, as shown in Figure 9. 1.

  • Page 26: Indoor Pendant Model

    Indoor Pendant Model The indoor pendant model mounts on a Vicon mount (refer to the table in the Introduction section) or a 1.5- inch vertical pipe with an appropriate coupling. The pipe is a standard 1.5-inch NPT type and must be oriented vertically so the SurveyorVFT can effectively hang from the pipe.
  • Page 27 Figure 12 Unlatching the Customer Interface Board b) Refer to Wiring section and Tables 2A, 2B and 2C to make all connections to terminal block TB1 (power), TB2 (alarms), TB3 (relays/control signals) and TB4 UTP video). On TB3, the COMMAND IN + (COMM IN +) and COMMAND IN - (COMM IN -) connections must be used for Simplex operation.
  • Page 28 12. Lift the SurveyorVFT camera drive up to the housing and attach the housing’s safety cord clip to the camera drive’s tab. See Figure 13. Allow the drive to hang from the housing. Insert the clip of the safety cord from the lower dome into the hole on the inside of the housing.

  • Page 29: Outdoor Pendant Model

    Outdoor Pendant Model The Outdoor Pendant model mounts on a Vicon mount (refer to the table in the Introduction section) or a 1.5- inch vertical pipe with appropriate coupling in the same manner as the indoor version. The outdoor version includes a sunshield, heater and weather protection.
  • Page 30 a) Strip approximately 1 inch (25 mm) of the cable outer jacket to be terminated in terminal blocks TB1 and TB3. Then strip approximately 0.25 inches (6 mm) of insulation off of each individual wire. b) Refer to Wiring section and Table 2 to make all connections to terminal block TB1 (power), TB2 (alarms), TB3 (relays/control signals) and TB4 UTP video).
  • Page 31 14. Push camera drive straight up into the housing until snaps into housing. excessive force. In the event that it does not snap easily, remove SurveyorVFT and verify proper cabling. 15. Holding the lower dome, line up the 2 molded tabs on the lower dome with...
  • Page 32 Figure 18 Outdoor Lower Dome Installation 24 • Installation XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...
  • Page 33 NOTES Installation • 25 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 34: Wiring

    Table 4 of the Technical Information section. Refer to the table in the Introduction for power supplies available from Vicon (single and multi-channel). In the standard version, video cables carry the composite video signal and Vicoax signals out of the SurveyorVFT over coaxial cable.
  • Page 35 Figure 19 Customer Interface Board Connections Wiring • 27 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 36: Typical Relay And Alarm Connections

    Typical Relay and Alarm Connections Alarm input and relay output type signals are also carried on individually-shielded twisted-pair cable sets. The signals are defined in the following descriptions. Alarms 1-4 are electronic CMOS level type inputs that are driven by a dry contact type switch. These signals are connected to terminal block TB2.

  • Page 37: Installing The Cables

    Installing the Cables WARNING: Disable the AC power to prevent installer injury and damage to the unit. Cables are installed using 2 different methods, depending on the installation type. For the in-ceiling installation, cables are routed from above the ceiling through a conduit fitting on the enclosure to the customer interface board.

  • Page 38: For An Indoor Or Outdoor Pendant Model Installation

    For an Indoor or Outdoor Pendant Model Installation Refer to Figure 19 customer interface boards for indoor or outdoor pendant model mount cable installation details. 1. Route each cable from the inside top of the housing. 2. Remove terminal blocks from the accessory kit. The 2-pin is for power, the two (2) 8-pin are for alarms and control/relay;...
  • Page 39 CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER BNC (female) VIDEO (J1) Video output VIDEO AMP Header (Fiber Optic board)* Video/RS-422 data TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TERMINAL BLOCK ALARM (TB2) TB2-1 ALARM 1 Alarm input 1 TB2-2 Ground TB2-3 ALARM 2...
  • Page 40 CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER TERMINAL BLOCK VIDEO NVT (TB4) TB4-1 Unshielded twisted pair + UTP + TB4-2 UTP - Unshielded twisted pair - TB4-3 TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TERMINAL BLOCK ALARM (TB2) TB2-1 ALARM 1 Alarm input 1 TB2-2...
  • Page 41 CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TERMINAL BLOCK ALARM (TB2) TB2-1 Alarm input 1 ALARM 1 TB2-2 Ground TB2-3 ALARM 2 Alarm input 2 TB2-4 Ground TB2-5 Alarm input 3 ALARM 3 TB2-6 Ground TB2-7...

  • Page 42: Installation Configurations

    The star configuration requires the use of a Distribution Line Control, such as Vicon’s V1400X-IDL that can support up to 10 domes. Refer to the figure below for an illustration of sample configurations. Both types of configurations can be used within a system.

  • Page 43: Installing The Flash Upgrade And Pc Direct Control

    Additionally, software for the PC must be ordered; the disk provides both the flash upgrade utility, needed to upgrade the firmware in the dome to latest version, and the PC Direct Control Software, which allows a host PC to control several domes through a GUI. Call Technical Support at 1-800-34-VICON (1-800-348-4266). Standalone Configuration Vicon recommends the standalone configuration, connecting the output of the RS-232/RS-422 converter directly to the SurveyorVFT data line.

  • Page 44: Star Configuration

    Standalone Configuration System Star Configuration When multiple domes are connected in a star configuration, using a V1400X-IDL, the RS-232/RS-422 Interface Converter is used, part number 1240-5308-01, along with a customer fabricated cable. Refer to Table 2A for connections. In this configuration, connect the converter end of the customer-fabricated cable assembly to the SERIAL port of the computer and the other end to the CPU/J11 port on the V1400X-IDL (you may have to disconnect the keypad).
  • Page 45 Star Configuration System After the physical connections are made, insert the software disk and select the appropriate program, Flash Upgrade Utility or PC Direct Control Software. Wiring • 37 XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 46: Configuration

    Configuration The SurveyorVFT must be configured for its address and mode and termination setting when using RS- 422/RS-485 protocol. The address and mode are set using the two 8-position DIP Switch banks SW1 and SW2. It is necessary to determine which communication mode, Camera/Lens Module type and SurveyorVFT address is required prior to configuration.
  • Page 47 NOTE: DIP switches labeled ON or CLOSED and OFF or OPEN have the same meaning. Competitive Protocol Settings, Switches 5-8 Pelco: Switch 5 is ON, switches 6-8 are OFF Sensormatic: Switch 6 is ON, switches 5, 7, 8 are OFF Ultrak: Switches 5 and 6 are ON, switches 7-8 are OFF Philips: Switch 7 is ON, switches 5, 6, 8 are OFF Cohu: Switches 5 and 7 are ON, switches 6 and 8 are OFF...
  • Page 48 DIP Switch 1 (SW1) Address (NOVA/VPS Mode) SWITCHES SWITCHES SWITCHES Table 3 DIP Switch 1 (SW1) Settings for NOVA/VPS Mode 40 • Configuration XX134-01-00 Rev 205 SurveyorVFT Camera Dome System...

  • Page 49: Setting The End-Of-Line Jumpers Jp1, Jp2 & Jp3 For Rs-485 Protocol Operation

    Setting the End-of-Line Jumpers JP1, JP2 & JP3 for RS-485 Protocol Operation This section defines setting the end-of-line jumpers JP1, JP2 and JP3. The jumper sockets are located on the underside of the customer interface board, shown in Figure 24. Figure 24 End-of-Line Jumper Location NOTE: DIP Switch 2 (SW2) switch 4 must be set to the ON (RS-485) position for proper daisy chain...

  • Page 50: Configuring The Network Settings

    Configuring the Network Settings Note: Before starting, make sure that VNSetup.exe is installed on the configuring PC\workstation. Installation is done using the SurveyorVFT Software CD included. There are two ways to change the IP dome network settings: • Activating the camera for the first time: via VNSetup.exe application. •...

  • Page 51: Upgrading Software Version

    Upgrading Software Version The upgrade software procedure requires the VNSetup utility to install a new version. Follow the steps below. Load the new IP dome software CD (provided) to the PC/workstation. Installation script will start automatically. (If not, double click on the Setup.exe icon in the CD drive.) Follow the instructions on screen.

  • Page 52: Viconnet Configuration

    ViconNet Configuration After the camera dome has been setup with the proper IP address, configuration features from a remote workstation, server or recorder are available as follows. • A network settings screen is used to modify the camera dome’s IP parameters. This allows great flexibility in network setup.

  • Page 53: Viconnet (Ip/Lan) Version Operation

    ViconNet (IP/LAN) Version Operation The following functions are supported by the ViconNet system through a workstation, recorder or server. 1. System macros can be configured to view and record the dome’s video. In addition, within macros, alarms can be sent and remote macros triggered. 2.

  • Page 54: Uninstalling The Surveyorvft

    Uninstalling the SurveyorVFT The SurveyorVFT camera drive can be easily uninstalled by simply pushing in the tabs to release the camera drive from the housing or the enclosure. A safety cord is always available to safely hang the camera drive or camera dome assembly while installing or uninstalling.

  • Page 55: Operation

    When initial power-up has been completed and verified, SurveyorVFT can be setup and operated in a normal fashion using a Vicon remote operator keypad, VPS/NOVA unit or through a PC running the Surveyor Direct Control program; the ViconNet can be run from a ViconNet workstation.

  • Page 56: Verifying Proper Operation

    SurveyorVFT. Power-on the control device and verify that it boots up. Set up the control device for operation with the SurveyorVFT in accordance with its Installation and Operation Manual. For a Vicon model V1300X-RVC or V1300X-DVC keypad connected directly to the SurveyorVFT or through a CPU, use the following procedure to access SurveyorVFT programming: 1.

  • Page 57: Troubleshooting

    1. Slide the keypad’s PGM-RUN switch to the PGM position. 2. Press the PP ENTER key; the PRESET LED displays a blinking 0. 3. Press the 9 and 5 numeric keys in that order. 4. Press the PP ENTER key again. The PRESET LED display remains with the number 95. The monitor will display the power-up test screen (Figure 26) for the duration of its initial testing.

  • Page 58: Competitive Protocols

    Note: All companies make changes and improvements in their products. Because this product can interface with equipment not manufactured by Vicon, there is a possibility that the interface protocols may have changed since Vicon tested this product with the interfacing equipment. Vicon recommends purchasing a single unit for bench testing prior to purchasing and installing this product in quantity.
  • Page 59 Focus Far Debug Screen Focus Far The controller MPT9500 doesn't support Pelco tours. Vicon's tours are accessible using presets 80-87 or the menu system. To store a tour, Enter preset number, Preset Set , F2. To run tour use Zoom Out...
  • Page 60 Repeat Pattern to repeat. Camera Off Not Supported Night Mode- Manual Not Supported Vicon Menu Alarms are not used. Alarms are alw ays enabled. The dome w ill report to the AD keypad w hich alarm is activated (1-4) Camera On...
  • Page 61 Kalatel Function Keypress Function Keypress Press Set until "Enter Programming Code" appears. Enter Access Code 951followed by SEQ. Select 4 - Cyberdome. Enter three digit camera number. Enter 1 when prompted "Does The Monitor Display Site XXX". Enter Menu Program the unit using the joystick. Set Transmit Polarity Not Supported Not Supported;...
  • Page 62 Ultrak When changing SurveyorVFT software addresses, the keypad may not respond to all 256 addresses. The workaround is to go to Ultrak KEGS Setup menu, option (3.1.2) and set every camera (256) to KD6. Function Keypress Function Keypress Enter SurveyorVFT address on keypad and hit Enter key.
  • Page 63 Panasonic Function Keypress Function Keypress Press and hold CAMERA SETUP button for 2 sec. Use SET button to select and save options. Use ESC button to abort or leave options. Move joystick up and down to select and highlight SurveyorVFT preset 94 menu options. Use button AUX 1 for Aux 1 and AUX 2 for Aux 2.
  • Page 64 Philips Function Keypress Function Keypress Use On-46-Enter shortcut to enter Dome menu. Use Focus Far button to select and save options. Use Iris Close button to abort or leave options. Move joystick up and down to select and highlight Dome menu options (joystick does not support "press and hold"...
  • Page 65 Cohu Function Keypress Function Keypress To launch Dome menu use Preset 64 + Store. Use Focus Far button to select and save options. Use Iris Close button to abort or exit options. Move mouse cursor up and down on Not Supported Pan/Tilt pane to select and highlight Dome menu options.

  • Page 66: Maintenance

    Maintenance The SurveyorVFT requires no scheduled maintenance; however, the Lower Domes require occasional cleaning. The Chrome and Gold Domes are referred to as Metallized type domes. The Clear and Smoked Domes are referred to as Acrylic type domes. All domes require careful handling and occasional cleaning. Care and Cleaning of Metallized Domes 1.

  • Page 67: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.

  • Page 68: Reference

    Coaxial Cable Recommendations Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms.

  • Page 69: Twisted-Pair Cable

    Table Recommended Individually-Shielded, Twisted-Pair Cable Types UTP Connection For NVT models, where video is transmitted over twisted-pair cable, a UTP receiver is required. Vicon offers three receivers to provide video transmission over a range of distances. NVT Receiver Wire Gauge...

  • Page 70: Network Cable

    Network Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use pure copper stranded conductors to obtain a low DC resistance. The preferred insulation and cable jacket is Polyvinyl chloride (PVC).

  • Page 71: Technical Information

    Technical Information Zoom and Focus Speed: Less than 1.8 sec from end to end. ELECTRICAL Electrical motorized pan and tilt Drive Type: Sectoring: 16 max, programmable for size and with electronic control. titling; capability to be blanked out (22XEX and 23X only). Units available in color and day/night Camera Types: (NTSC/PAL) formats and a variety of...
  • Page 72 22X). Because this product can interface with equipment not manufactured by Multilanguage Menu: English, Spanish, French, German Vicon, there is a possibility that the and Italian. interface protocols have Day/Night (23X) Features: 6 programmable motion detection changed since Vicon tested this zones with 3 sensitivity levels;...

  • Page 73: Video Transmission

    Mounting: -40 to 150° F (-40 to 65° C). Temperature Range: In-ceiling or indoor/outdoor pendant. 0 to 90% relative, non-condensing. Storage Humidity Range: See Table 1 for compatible Vicon mounts. Outdoor unit IP66. IP Rating: Housing Types: Indoor Pendant: IP52.

  • Page 74: Camera Specifications

    Table 5: Camera/Lens Specifications Model Numbers SVFT-C22, SVFT-P22, SVFT-C22C, SVFT- SVFT-C23, SVFT-P23, SVFT-C23C, SVFT- SVFT-W22 P22C, SVFT-W22C SVFT-W23 P23C, SVFT-W23C Product Codes Camera Specifications 8701-00, 8704-00, 8701-01, 8704-01, 8702-00, 8705-00, 8702-01, 8705-01, 8707-00 8707-01 8708-00 8708-01 Formats NTSC NTSC Type...
  • Page 75 Model Numbers SVFT-C22CA, SVFT-P22CA, SVFT-W22CA SVFT-C22CA-C, SVFT-P22CA-C, SVFT-W22CA-C Camera Product Codes Specifications 8741-00, 8742-00, 8743-00 8741-01, 8742-01, 8743-01 Formats NTSC Type Color Color Optical Zoom Digital Zoom 264X 264X Total Zoom OPTICAL wide/DIGITAL tele: 3.9 sec OPTICAL wide/DIGITAL tele: 3.9 sec Zoom Speed Image Device 1/4-inch interline transfer CCD...

  • Page 76: Vicon Standard Equipment Warranty

    Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion.
  • Page 77 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
