Quick Guide for
SurveyorVFT Camera Domes
Warning: To reduce a risk of fire or electric shock, do not expose the indoor unit to rain or moisture.
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements
or that the operation will be entirely error free or perform precisely as described in the documentation. This
system has not been designed to be used in life-critical situations and must not be used for this purpose.
Vicon part number: 8009-8134-60-02
Copyright ©2016 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks or Vicon Industries Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SurveyorVFT and is the answer not in the manual?

Questions and answers

Related Manuals for Vicon SurveyorVFT

Summary of Contents for Vicon SurveyorVFT

  • Page 1 Warning: To reduce a risk of fire or electric shock, do not expose the indoor unit to rain or moisture. Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.

  • Page 2: Important Safeguards

    5. Installation and Wiring - The equipment shall be installed and The product shows a significant change in performance. wired in accordance with the National Electrical Code, 21. Replacement Parts - Use only Vicon specified replacement ANSI/NFPA 70. parts or an approved equivalent to prevent unit damage and 6.
  • Page 3 Introduction This Quick Guide provides an overview for installing the standard SurveyorVFT PTZ Camera Dome, the SVFT-M Impact-Resistant model, the SVFT-PRS Pressurized version and the SurveyorVFT Fixed models. An abbreviated programming guide is also provided for the camera domes, excluding the fixed versions.
  • Page 4 Quick Installation – Standard PTZ In-Ceiling Model...
  • Page 5 Quick Installation – Standard PTZ Indoor Pendant...
  • Page 6 Quick Installation – Standard PTZ Outdoor Pendant...
  • Page 7 Quick Installation – SVFT-M Impact Resistant...
  • Page 8 Quick Installation – SVFT-PRS Pressurized Pressurize the housing with Dry Nitrogen gas according to the procedure in this manual. Reinstall cap on fill valve. Reinstall service cover...
  • Page 9 Quick Installation – Fixed In-Ceiling (Access to Ceiling)
  • Page 10 Quick Installation – Fixed In-Ceiling (No Access to Ceiling)
  • Page 11 Quick Installation – Fixed Indoor Pendant...
  • Page 12 Quick Installation – Fixed Outdoor Pendant...

  • Page 13: Wiring And Setup

    Wiring and Setup Pin Connections – Standard SurveyorVFT and SVFT-M *J2 for optional fiber optics interface board that provides video and RS-422 full duplex data through a standard fiber optics connector. Wiring Connections – Standard Coaxial/Fiber Optic Versions Wiring Connections – UTP Version...
  • Page 14 Wiring Connections – ViconNet Version Pin Connections – SVFT-PRS Prefabricated cable On coaxial and UTP units, L, M, X and U are not used. On fiber units L, M, J, K, X and U are not used. On ViconNet units, A, C, D, P, T, L, M, J, K. X, and U are not used.
  • Page 15 Pin Connections – SurveyorVFT Fixed Both power and video connections are made to the integral printed circuit board (PC board) on the camera mechanism. The PC board provides a board-mounted BNC connector for coaxial, a screw terminal for twisted pair video, an ST connector for fiber-optic or an RJ-45 connector on the ViconNet board for video connection and a removable two-position screw terminal connector for camera power.

  • Page 16: Software Features

    Software Features Most of the SurveyorVFT features are accessed remotely through either a keypad or a PC using the SurveyorVFT Configurator software package. To program certain features, a numeric preset is either stored or recalled. Preset functions can represent a variety of features.
  • Page 17 90 has no effect. The camera dome retains its capability of zoom, focus and iris control while locked. Preset 93 (Set Response Line Polarity) (Duplex Only) — The SurveyorVFT checks for polarity of the command in lines through the auto baud detect feature. The baud detect cycles through 4800+/4800- /9600+/9600-/19200+/19200-, indicating not only the baud rate it is searching for but also the polarity that the receive lines are set to.

  • Page 18: Programming Menus

    Recalling preset 97 has no effect. Preset 98 (Programming Autopan Limits) — When a SurveyorVFT is selected on a keyboard, pressing the AP (autopan) key will start the camera in motion, panning at a predetermined speed.

  • Page 19: Pressurizing The Housing Assembly (Svft-Prs)

    Relay Driver — Adjusts and configures the relay output for control of external devices. Source Titling — Programs and displays the various titles available to the SurveyorVFT. Note: All titles are disabled from the factory and will not be displayed upon initial startup.
  • Page 20 Warning: If the dome has been dropped and is cracked, do not pressurize. Replace it with a new dome. Note: Leakage rate is less than 2 psi per year. Note: The housing with mechanism has approximately 490 in. of volume. Note: The pressurized function has not been evaluated by UL.
  • Page 21 Placement (2 places) HEATER DUCT INSTALLATION (THIS APPLIES FOR ALL SURVEYORVFT OUTDOOR INSTALLATIONS) An optional heater duct must be installed in any SVFT Outdoor unit. Its installation is similar for the various types of SVFT (Std. PTZ, Fixed, Maximum Security or Pressurized) Domes and is beneficial in low temperature applications in that it directs warm air onto the lower bubble surface minimizing icing and fogging I condensation problems.
  • Page 22 For the duct to work effectively, the defog mode for fan operation (not applicable for fixed units) must be evoked. For all versions of firmware prior to Version 1.2.0 a firmware upgrade (Version 1.08.1 minimum) is required to be able to access this mode, which should be installed in conjunction with installing the duct.

  • Page 23: Vicon Standard Equipment Warranty

    “autopan” or “tour” modes of operation. Such continuous operation is outside the scope of this warranty. 11. Any product sold as “special” or not listed in Vicon’s commercial price list: One year from date of original retail purchase.
  • Page 24 Except as provided in this written warranty and to the extent permitted by law, neither Vicon nor any affiliated shall be liable for any loss, (including loss of data and information), inconvenience, or damage, including, but not limited to, direct, special, incidental or consequential damages, resulting from the use or inability to use the Vicon product, whether resulting from breach of warranty or any other legal theory.
  • Page 25 Vicon Industries Inc. For office locations, visit the website: www.vicon-security.com...
