XX152-02-00
FIXED CAMERA DOME
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet
your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in life-critical
situations and must not be used for this purpose.
Copyright © 2004 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44 (0) 1489-566300
WEB: www.vicon-cctv.com
Vicon part number 8009-8152-02-00
Rev 1204 Section 3
Advertisement
Table of Contents
Related Manuals for Vicon XX152-02-00
Summary of Contents for Vicon XX152-02-00
- Page 1 XX152-02-00 FIXED CAMERA DOME Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 3: Fcc Notice
FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class A computing device in accordance with the specification in subpart B of part 15 of the FCC rules, which are designed to provide reasonable protection against such interference in a commercial installation. -
Page 4: Important Safeguards
Important Safeguards GRAPHIC SYMBOL EXPLANATION The lightening bolt symbol alerts the user to the presence of dangerous voltage that may present the risk of electric shock. The exclamation point symbol alerts the user to the presence of important operating and maintenance instructions. 1. -
Page 5: Table Of Contents
DIP Switch Settings...10 Camera Synchronization ...10 Autoiris Adjustments ...10 Final Installation ...12 Disassembly...16 Operation ...17 Maintenance ...17 Care and Cleaning of Lower Dome...17 Fuse Replacement...17 Shipping Instructions ...18 Reference...19 Technical Information ...21 XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome Contents • i... -
Page 6: Quick Installation
Quick Installation In-Ceiling - No Access to Ceiling ii • Quick Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... - Page 7 In-Ceiling – Access to Ceiling Quick Installation • iii XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome...
- Page 8 Pendant - Indoor iv • Quick Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome...
- Page 9 Pendant – Outdoor Quick Installation • v XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome...
-
Page 11: Introduction
*Note: Each model is also available in a twisted pair (UTP) version. Simply add a “-T” to the model number and a -40 to the product code (ex., SVFT-C266M-T, 8725-40; SVFT-C266M-TC, 8725-41). XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Table 1 Models, Product Codes and Descriptions In-ceiling;... -
Page 12: Installation
Make arrangements for a representative of the carrier to inspect the damaged equipment. If the equipment must be returned for repair, follow the Shipping Instructions at the end of this manual. 2 • Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... -
Page 13: Surveyorvft Fixed Dome Components
Sunshield A sunshield pre-installed over the housing used on the outdoor pendant version is for radiation sun-blocking protection. CAUTION: For any environment subject to moisture, use the outdoor pendant model. Installation • 3 XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome... -
Page 14: Mounting The Unit
1. Mark with the scribe and cut a 7-3/8 in. (187 mm) hole in the ceiling at the desired location. Remove the tile from a dropped ceiling if necessary. Feed all necessary flexible conduit pipe or cables down through the hole. 4 • Installation In-Ceiling Mounting Figure 1 Use of the Scribe XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... -
Page 15: Mounting From Above The Ceiling
Insert the camera mechanism into the enclosure until it snaps into place. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome and route cables through the strain relief fitting. -
Page 16: Optional Independent Support
SVFT-IC-MKT. It consists of a pre-assembled set of ed against the tile without warping the tile. Refer to e previous procedure. When using this kit, the flippers Figure 3A XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... -
Page 17: Indoor Pendant
Add 1 in. (25 mm) of extra length to each cable for termination (if not previously terminated) and cut them. The approximate length of each cable should be 14 - 15 in. (356 - 381 mm). Continue with the section on Cable Connections. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Figure 3B Indoor Pendant... -
Page 18: Outdoor Pendant
PC board. Pin 1 is for Video and Pin 2 is Ground; Pin 3 is Not Used. Refer to Figure 4. Refer to the instructions supplied with the receiver for those connections. 8 • Installation Outdoor Pendant Coaxial Video Cable Twisted-Pair Video Cable XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome e area around the... -
Page 19: Camera Power Connections
Table 2. 3. Press the cable connector onto the board connector. The connector is keyed to installation. The camera is shipped prepared for 24 VAC. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Figure 4 Camera/Lens PC Board Table 2... -
Page 20: Dip Switch Settings
Figure 5. Use a small jeweler’s screwdriver to make adjustments. Turning the potentiometer opens and closes the iris to regulate light extremes. Turning the potentiometer clockwise opens the iris wider, allowing more light. Autoiris control is DIP switch selectable. 10 • Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... - Page 21 Figure 5 Potentiometer/DIP Switch Location Figure 6 DIP Switch Settings Installation • 11 XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome...
-
Page 22: Final Installation
In some installations, the picture may be “squared up” by rotating the lens about its own axis up to 360° (roll adjustment). Figure 7 Camera/Lens Adjustments – 5-50 mm Version Shown 12 • Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... - Page 23 Press the lower dome into the SurveyorVFT and verify that it snaps into place on both sides. The upper edge of the lower dome should be flush with the ceiling plane. Refer to Figure XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Figure 8 Figure 9...
- Page 24 Press the lower dome into the Figure 10 Pendant Mount Dome Final Installation XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome until it snaps into be adjusted. rtical position of the is the front ring, iris...
- Page 25 SurveyorVFT and verify that it snaps into place on both sides. Tighten the four (4) trim ring screws to hold the lower dome in place. Refer to Figure 10. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Outdoor Pendant Installation • 15...
-
Page 26: Disassembly
SurveyorVFT, remove all ca XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome camera mechanism while il all molded tabs snap out of il all molded tabs snap out of... -
Page 27: Operation
There is a fuse located in the SurveyorVFT. When necessary, replace it with a fuse of the same value, 0.5 A, 250 V, 5x20 mm slo blo for indoor version; the outdoor version has an additional 1.0 A, 250 V, 5x20 mm slo blo fuse. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Operation • 17... -
Page 28: Shipping Instructions
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection. 4. Mark the R.A. number on the outside of the carton on the shipping label. 18 • Shipping Instructions d the R.A. XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome... -
Page 29: Reference
Inside diameter: 1.61 inches (40.9 mm). Wall thickness: 0.145 inches (3.37 mm) minimum (ANSI “standard” grade thickness). XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome eferred dielectric material is cellular (foam) RG-59/U and RG-11/U. Each is actually a family of cables with widely varying... -
Page 30: Twisted-Pair Cable
8Ω 10Ω 13Ω 16Ω 20Ω 25Ω 32Ω 40Ω Polyethylene Bare Copper XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome gnals effectively for long distances. The and resists flames, and maximum distances listed below. The 8Ω 13Ω 10Ω 16Ω 13Ω 21Ω 17Ω... -
Page 31: Technical Information
3 axis adjustment, pan (360°), tilt (95°) and roll (lens m MECHANICAL Applica tion: Indoor and outdoor mode Mounti In-ceiling and pendant models. XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome sent the conversion of 100% of the electrical energy to Maximum Distance ft (m) Indoor 600 (183) 938 (286) (457) - Page 32 -40 to 150° F (-40 to 65° C). Storage Humidity: Up to 90% relative, noncondensing. Wind Load: Outdoor: heavy rain or snow driven by winds up to 80 mph. 22 • Technical Information 0° C). XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome...
- Page 33 2:1 interlace, NTSC/PAL 1/3 ” ExView SVFT-W266A/ CCD, SVFT-W266A-C 2:1 interlace, NTSC/PAL 1/3” CCD, SVFT-W550A/ 2:1 interlace, SVFT-W550A-C NTSC/PAL XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome Table 3 Camera Specifica lor/ Resolution Sensitivity Synch roni zation V li nes) fc (lux) Color (0.8...
- Page 34 82.05° - 38.26° 2.6-6 varifocal with autoiris 106° - 47.6° 5-50 varifocal with autoiris 51.8°- 5.6° XX152-02-00 Rev 1204 SurveyorVFT Fixed Camera Dome Vertical 78.2°- 35.8° 78.2°- 35.8° 39.2°- 4.3° 78.2°- 35.8° 78.2°- 35.8° 39.2°- 4.3° 60.32°- 28.66°...
- Page 35 COMPANY’S WEBSITE, WWW.VICON-CCTV.COM. IN THAT EVENT, THE TERMS OF THE POSTED WARRANTY SHALL APPLY EXCLUSIVELY. Vicon Part Number: 8006-9010-03-01 Rev 804 XX152-02-00 Rev 1004 SurveyorVFT Fixed Camera Dome be free from defects in material and workmanship under three years, with the following exceptions: retail purchase.
- Page 36 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 6 31-9 51-CCT V (2 288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX nite d Kingd +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E Leuv...
