Comtech EF Data CDM-Qx Installation And Operation Manual page 203

CDM-Qx Satellite Modem
Remote Control
Command
Parameter (Instruction
Type Code and
qualifier)
BUC Low Current BCL=
Limit
(L-Band Unit
only)
BUC LO BLO=
Frequency
(L-Band Unit
only)
BUC Output N/A
Power Level
(L-Band Unit
only)
BUC N/A
Temperature
(L-Band Unit
only)
BUC PLL Alarm N/A
(L-Band Unit
only)
BUC Software N/A
Version
(L-Band Unit
only)
Arguments
for
Command or
Response to
Query
4 bytes Command or Query
BUC Low Current Limit, a value between 100 and 3000 mA
Example: BCL=0600
6 bytes Command or Query
BUC transmit LO frequency information in the form: xxxxxs, where :
xxxxx is the LO frequency in the range of 3000 to 65000 MHz
All 0's (000000) disables the feature
S is the sign for the mix (+ or – character)
Terminal Frequency= BUC LO TFQ
Example: BLO=12000+ (BUC LO is 12 GHz, low-side mix)
4 bytes Query only
BUC output power level in the form xxx, where xxx is the value in
watts.
Example: BOL=08.3 (BUC reports output is 8.3 watts)
Returns 00.0 when FSK and BUC power are not enabled.
4 bytes Query only
Indicates BUC temperature, in the form: sxxx
Where:
s=sign (+ or – character)
xx=value
If not available, response is –99
Example: BUT=-13 (BUC temperatures is -13°C)
Note: This query is only valid when the FSK and BUC power are turned On.
1 byte, value of Query only
0,1 BUC PLL lock state, where:
0=Unlocked
1=Locked
Example: BPA=1 (BUC PLL is locked)
Note: This query is only valid when the FSK and BUC power are turned On
3 bytes Query only
Indicates the BUC software version, in the form: x.x
Example: BSV=1.1 (Software version 1.1)
Note: This query is only valid when the FSK and BUC power are turned On
Description of arguments
C-37
Response to Query
Command (Instruction
(Target to Code and
Controller) Qualifier)
BCL= BCL?
BCL?
BCL*
BCL#
BCL^
BLO= BLO?
BLO?
BLO*
BLO#
BLO^
N/A BOL?
N/A BUT?
N/A BPA?
N/A BSV?
Revision 6
MN/CDMQx.IOM
Response to query
(Target to
Controller)
BCL=xxxx
(see description of
arguments)
BLO=xxxxxs
(see description of
arguments)
BOL=xx.x
(see description of
arguments)
BUT=sxx
(see description or
arguments)
BPA=x
(see description of
arguments)
BSV=x.x
(see description of
arguments)
