CDM-Qx Satellite Modem
Ethernet Management (Base Modem)
To see the configuration of the cards which are grouped as modem, just click on the
icon (single click only). Clicking any of these icons highlights them, as illustrated in the
next example:
As shown, both the
and demodulator parameters are accessible.
If icon is selected, only the modulator parameters will be displayed and accessible. If
TX
RX icon is selected, only the demodulator parameters will be displayed and accessible.
and icons are highlighted. In this case, both the modulator
MD Config
11–5
Revision 6
MN/CDMQx.IOM
MD
