CDM-Qx Satellite Modem
Remote Control
Command
Parameter (Instruction
Type Code and
qualifier)
OGC Outdoor OGC=
Unit Global
Configuration
(L-Band Unit only)
Arguments
for
Command or
Response to
Query
50 bytes Command or Query
ODU Global Configuration in the form:
aabcdexxxxhhhiiiijjjjjkxxxxxxlmnnnooopppppqxxxxxx, where:
aa=BUC Address
b=BUC FSK comms enable
c=BUC Power Control
d=BUC 10 MHz Freq Ref Enable
e=BUC TX Output Enable
xxxx=expansion bytes
hhhh=BUC Low Alarm Limit
iiii=BUC High Alarm Limit
jjjjjk=BUC LO frequency, mix sign
xxxxxx=expansion bytes
l=LNB Power Control
m=LNB 10 MHz Freq Ref Enable
nnn=LNB Low Alarm Limit
ooo=LNB High Alarm Limit
pppppq=LNB LO Freq, mix sign
xxxxxx=expansion bytes
Any unavailable parameters will be filled with
xxx.
Description of arguments
same as BAD
same as BCE
same as BPC
same as BFR
same as BOE
same as BCL
same as BCH
same as BLO
same as LPC
same as LFR
same as LCL
same as LCH
same as LLO
C-35
Response to Query
Command (Instruction
(Target to Code and
Controller) Qualifier)
OGC= OGC?
OGC?
OGC*
OGC#
OGC^
Revision 6
MN/CDMQx.IOM
Response to query
(Target to
Controller)
OGC= aabcde
xxxxhhhiiiijjjjjkxxxxxxlm
nnnooopppppqxxxxxx
(see description of
arguments)
Where: n=0 to 9
Returns the OGC
portion of 1 of 10
stored configurations
(see description of
arguments)
