CDM-Qx Satellite Modem
Remote Control
Command
Parameter
(Instruction
Type
Code and
qualifier)
Alarm Mask
MSK=
Local/Remote
LRS=
Status
AUPC Enabled
AUP=
(Modem only)
AUPC
APP=
Parameters
(Modem only)
Arguments
for Command
Description of Arguments
or Response
to Query
12 bytes
Command or Query
Alarm mask condition, in form abcdefghijkl, where:
a=TX FIFO (0=Unmasked, 1=Masked, X=no Tx)
b=G.703 BPV (0=unmasked, 1=Masked, X=no Tx)
c=Tx-AIS (0=Unmasked, 1=Masked, X=no Tx)
d=RX AGC Alarm (0=Unmasked, 1=Masked, X=no Rx)
e=Eb/No Alarm (0=Unmasked, 1=Masked, X=no Rx)
f=RX-AIS (X=no Rx)
g=Buffer Slip (X=no Rx)
h=EXT REF Alarm
i=BUC Alarm (L-Band unit only)
j=LNB Alarm (L-Band unit only)
k=Spare
l=Spare
Example: MSK=010110010100
1 byte, value of
Command or Query
0, 1
Local/Remote status, where:
0=Local
1=Serial Remote
3=Ethernet Remote
Example: LRS=1 (Serial Remote)
1 byte, value of
Command or Query
0, 1
AUPC mode enable/Disable, where:
0=Disabled
1=Enabled
Example: AUP=1 (Enabled)
Note: EDMAC framing must be selected for the AUPC feature to work.
6 bytes
Command or Query
Defines AUPC operating parameters. Has the form abc.cd,
where:
a=Defines action on max power condition
(0=do nothing, 1=generate TX Alarm)
b=Defines action on remote demod unlock.
(0=go to nominal power, 1=go to max power)
c= target Eb/No value, for remote demod, from 0.0 to
9.9 dB
d=Max increase in Tx Power permitted, from 0 to 9 dB
Example: APP=015.67 (sets no alarm, max power, 5.6 dB target
and 7 dB power increase)
MSK=
MSK?
MSK*
MSK#
MSK^
LRS=
LRS?
LRS*
LRS#
AUP=
AUP>
AUP*
AUP#
AUP^
APP=
APP?
APP*
APP#
APP^
C-18
Response to
Query
Command
(Instruction
(Target to
Code and
Controller)
Qualifier)
MSK?
LRS?
AUP?
APP?
Revision 6
MN/CDMQx.IOM
Response to
query
(Target to
Controller)
MSK=abcdefghijkl
(see description or
arguments)
LRS=x
(see description of
arguments)
AUP=x
(see description of
arguments)
APP=abc.cd
(see description of
arguments)
