iPF765
5
Holding the Roll Holder flange (a), guide the holder
along the Roll Loading Slots (b) on both ends, keep-
ing the holder level as you load it in the Roll Holder
Slot.
•
Do not force the Roll Holder into the printer with the right and left ends reversed. This may damage the printer
and Roll Holder.
Caution
•
Do not release the flanges until the holder is loaded in the Roll Holder Slot.
•
Be careful not to pinch your fingers between the Roll Loading Slots (b) and the Roll Holder shaft (c) when load-
ing rolls.
6
Advance the roll to insert the leading edge in the Pa-
per Feed Slot (a) until you hear a tone.
•
Be careful not to soil the printing surface of roll paper as you insert it in the slot. This may affect the printing
quality. We recommend wearing clean cloth gloves when handling rolls to protect the printing surface.
Important
•
If the paper is wrinkled or warped, straighten it out before loading it.
• Load paper straight so it is not fed askew.
7
Once paper feeding starts, you will need to do the following, based on the ManageRemainRoll setting and
the barcode printed on rolls. (See "Keeping Track of the Amount of Roll Paper Left.")
ManageRemain-
Barcodes
Roll
Off Printed
Not printed
On Printed
Not printed
User's Guide
Printer Operation After the Paper is Fed
A menu for selection of the type of paper is automatically shown on the Display Screen.
Press ▲ or ▼ to select the type of paper, and then press the OK button.
The type and amount of paper left is automatically detected based on the barcode printed on the roll.
There is no need to specify the type and length of the paper.
A menu for selection of the paper type and length is automatically shown on the Display Screen.
Press ▲ or ▼ to select the type and length of paper loaded, and then press the OK button.
Loading Rolls in the Printer
→P.410
