This feature is useful when you print the document enlarged or reduced with Scaling as well. When an image is
scaled, it is always enlarged or reduced in reference to a starting point in the upper left corner of the page. If the
Note
image is reduced, the bottom and right margins are enlarged and the top and left margins remain unchanged. At that
point, you can set all margins evenly with this feature.
• No Spaces at Top or Bottom
You can set the printer to print without any empty area when the print data contains empty area at the top or
bottom. Since the printer does not feed paper over the empty area, you can save paper.
•
Available only if rolls are selected in Paper Source.
Note
• Rotate Page
Select the method for rotating page.
The following settings are available for rotating page.
Setting
Rotate Right 90 Degrees
Rotate Left 90 Degrees
Rotate 180 degrees
•
Available only if rolls are selected in Paper Source.
Note
• Output Method Button
Click the button to open the Output Method dialog box.
In this dialog box, you can specify the object output method.
User's Guide
Rotates the portrait page right 90 degrees and print in landscape orientation. When the rotated
page can fit in the width of roll paper, the page is rotated automatically, and when it can not fit
in the width of roll paper, the page is not rotated.
*When Fit Roll Paper Width is selected under Enlarged/Reduced Printing, then the image is
enlarged or reduced after rotating to fit the width of the roll paper.
Rotates the portrait page left 90 degrees and print in landscape orientation. When the rotated
page can fit in the width of roll paper, the page is rotated automatically, and when it can not fit
in the width of roll paper, the page is not rotated.
*When Fit Roll Paper Width is selected under Enlarged/Reduced Printing, then the image is
enlarged or reduced after rotating to fit the width of the roll paper.
Allows you to rotate the image 180 degrees from the vertical to the right.
Output Settings Panel
Details
