Canon imagePROGRAF iPF765 User Manual page 180

Page Setup Sheet
• H
Orientation
Choose the printing orientation.
•
Making the Original Orientation Match the Paper Orientation
• K
Rotate Page 90 degrees (Conserve Paper)
Activate this setting to rotate the document image by 90 degrees before printing.
• Conserving Roll Paper by Rotating Originals 90 Degrees
• L
Paper Source
Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in Media Type on the Main sheet.
• M
Roll Paper Width
Choose the roll width.
For details on available roll widths, see " Paper Sizes
• N
Roll Paper Options
Complete optional roll paper settings. Click to display the Roll Paper Options dialog box.
A
Under Automatic Cutting, you can specify Yes or No and Print Cut Guideline.
• Cutting Roll Paper After Printing
B
Select Banner Printing when printing multiple pages continuously.
• Printing Multiple Pages Continuously
• P
Output Method
Click to display the Output Method dialog box, which enables you to complete the Output Method and Name
of data to be saved settings.
• Output Method dialog box
• O
Size Options
Click to display the Paper Size Options dialog box, which enables you to register additional paper sizes or
select the size system for use.
• Paper Size Options Dialog Box
• S
Defaults
Restores all settings on the sheet to the default values.
180
→P.394
→P.154
→P.117
→P.181
→P.182
→P.149
→P.137
"
iPF765
User's Guide
