Overview

1.1 About this Printer

The following drawing illustrates the basic exterior components and controls of the printer.
The model number can be found on the Serial Tag affixed to the rear of the unit. Use this
model number when referencing specific information within this manual. (Because optional
items are not present on all models, certain printer configurations may not appear in some
of the illustrations in this manual.)
Access Cover
Ribbon Supply Hub
Ribbon Take-Up Hub
Centerplate
Front Panel
Media Supply Assembly
(Hanger or Hub)
Printhead Assembly
Printhead Latch
Fascia
Ribbon Idler
Internal Rewinder
Media Sensor
Media Idler
Media Guide
1-2
