Datamax M-Class Mark II Maintenance Manual page 23

Step Action
Press MENU and then
2 raise the printhead
assembly.
3 Press ENTER.
Scroll to SENSOR
4 CALIBRATION and
press ENTER.
Press ENTER, and then
5
to proceed press YES.
6 Remove the media
from the Media Sensor
and then press ESC.
Proceed according to
the media type, and
then press ESC:
Die-cut: Peel labels
•
from the backing.
Insert the backing
under the Sensor Eye
Mark;
7 Notched: Insert the
•
notch under the
Sensor Eye Mark; or,
Reflective: Insert the
•
black mark facedown
under the Sensor Eye
Mark.
Continuous: Go to
•
Step 8.
(continued)
Adjustments and Maintenance
Displayed Message
ADVANCED MENU
MEDIA SETTINGS
MEDIA SETTINGS
MEDIA TYPE
SENSOR CALIBRATION
PERFORM CALIBRATION
PERFORM CALIBRATION
PERFORM CALIBRATION?
PERFORM CALIBRATION
REMOVE LABEL STOCK
PRESS ESC KEY
yyy
PERFORM CALIBRATION
SCAN BACKING
PRESS ESC KEY
yyy
2-13
Comment
You are in the ADVANCED
MENU.
You are entering MEDIA
SETTINGS.
Press EXIT to leave this
procedure.
Press NO to exit.
This sets the "empty"
parameter, where yyy is a
numeric value representing
the current sensor reading.
For reflective media, SCAN
MARK will be indicated.
This sets the TOF parameter,
where yyy is a numeric value
representing the current
sensor reading.
Never position a perforation
under the sensor when
sampling.
