Example 1. Enabling the MMU
; This routine provides software with a predictable way of enabling the MMU.
; After the CPWAIT, the MMU is guaranteed to be enabled. Be aware
; that the MMU will be enabled sometime after MCR and before the instruction
; that executes after the CPWAIT.
; Programming Note: This code sequence requires a one-to-one virtual to
; physical address mapping on this code since
; the MMU may be enabled part way through. This would allow the instructions
; after MCR to execute properly regardless the state of the MMU.
MRC P15,0,R0,C1,C0,0; Read CP15, register 1
ORR R0, R0, #0x1; Turn on the MMU
MCR P15,0,R0,C1,C0,0; Write to CP15, register 1
; For a description of CPWAIT, see
; "Additions to CP15 Functionality" on page 176
CPWAIT
; The MMU is guaranteed to be enabled at this point; the next instruction or
; data address will be translated.
3.1.3.3

Locking Entries

Individual entries can be locked into the instruction and data TLBs. See
"Cache Lock-Down Functions" on page 105
finds the virtual address translation already resident in the TLB, the results are
unpredictable. An invalidate by entry command before the lock command will ensure
proper operation. Software can also accomplish this by invalidating all entries, as
shown in
Locking entries into either the instruction TLB or data TLB reduces the available number
of entries (by the number that was locked down) for hardware to cache other virtual to
physical address translations.
A procedure for locking entries into the instruction TLB is shown in
page 75.
If a MMU abort is generated during an instruction or data TLB lock operation, the Fault
Status Register is updated to indicate a Lock Abort (see
and the exception is reported as a data abort.
® ®
Intel IXP45X and Intel IXP46X Product Line of Network Processors
Developer's Manual
74
® ®
IXP45X and Intel IXP46X Product Line of Network Processors—Intel XScale
Example 2 on page 75.
for the exact commands. If a lock operation
"Data Aborts" on page
Order Number: 306262-004US
®
Processor
Table 22,
Example 2 on
178),
