Advanced Setup - D-Link GO-DSL-N150 User Manual

User Manual
GO-DSL-N150
3.8.3

Advanced Setup

Choose Help > Advanced Setup, the page shown in the following figure
appears. This page that is displayed contains Firewall, Routing, NAT, QoS and
ADSL.
Firewall
Select this option can automatically detect and block Denial of Service (DoS)
attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack.
Routing
Select this Option will list the routing table information. You can also
Add/Edit/Drop the static route.
Routing :: Static Route
Select this option to set static Routing information.
Destination IP Address: This parameter specifies the IP network address of the
final destination.
IP Subnet Mask: Enter the subnet mask for this destination.
Gateway IP Address: Enter the IP address of the gateway. The gateway is an
immediate neighbor of your ADSL Router that will forward the packet to the
destination. On the LAN, the gateway must be a router on the same segment as
your Router; over Internet (WAN), the gateway must be the IP address of one of
the remote nodes.
Metric: Metric represents the "cost" of transmission for routing purposes. IP
Routing uses hop count as the measurement of cost, with a minimum of 1 for
directly connected networks. Enter a number that approximates the cost for this
link. The number need not to be precise, but it must between 1 and 15. In
practice, 2 or 3 is usually a good number.
Announced in RIP: This parameter determines if the ADSL router will include
the route to this remote node in its RIP broadcasts. If set to Yes, the route to this
remote node will be propagated to other hosts through RIP broadcasts. If No, this
route is kept private and is not included in RIP broadcasts.
60
