The following table describes the parameters of this page:
Field
Virtual Circuit
Status
VPI
VCI
ATM QoS
PCR
SCR
MBS
ISP
Description
You can select a virtual circuit from the
drop-list. Click PVCs Summary you can view
eight PVCs (from PVC0 to PVC7), and only
PVC0 status is activated by default.
You can select Activated or Deactivated for
currently selected virtual circuit.
The virtual path between two points in an
ATM network, ranging from 0 to 255.
The virtual channel between two points in an
ATM network, ranging from 1 to 65535.
Select the Quality of Service types for this
Virtual Circuit. The ATM QoS types include
CBR (Constant Bit Rate), VBR (Variable Bit
Rate) and UBR (Unspecified Bit Rate). These
QoS types are
parameters specified below, including PCR,
SCR and MBS. You can choose CBR, UBR,
rt-VBR or nrt-VBR.
Peak cell rate (PCR) is the maximum rate at
which cells can be transmitted along a
connection in the ATM network.
Sustain cell rate (SCR) is the maximum rate
that traffic can pass over PVC without the risk
of cell loss.
Maximum burst size (MBS) is the maximum
number of cells that can be transmitted at the
PCR.
You can choose Dynamic IP Address,
Static IP Address,
Bridge Mode.
17
GO-DSL-N150
all controlled
PPPoA/PPPoE
User Manual
by the
or
