D-Link GO-DSL-N150 User Manual page 22

Field
Default Route
TCP MTU Option
Dynamic Route
Direction
Multicast
Select Static IP Address in the ISP encapsulation to set static IP information.
You will need to enter in the Connection type, IP address, subnet mask, and
gateway address, provided to you by your ISP. Each IP address entered in the
fields must be in the appropriate IP form, which is four IP octets separated by a
dot (x.x.x.x). The Router will not accept the IP address if it is not in this format.
access to the Internet fails. Normally NAT is
enabled.
You can enable or disable the default route. If
enable this function, the current PVC will be the
default gateway to internet from this device.
You can set a tcp mtu value. The range is from
100 to 1500. The default is 0.
Select this option to specify the Routing
Information protocol (RIP) version. You can
select RIP1, RIP2-B or RIP2-M.
You can select None, Both, IN Only or OUT
Only to specify the RIP direction. None is for
disabling the RIP function. Both means the
ADSL Router will periodically send routing
information and accept routing information then
incorporate into routing table. IN only means
the ADLS router will only accept but will not
send RIP packet. OUT only means the ADLS
router will only send but will not accept RIP
packet.
You can choose Disabled, IGMP v1 or IGMP
v2.
19
GO-DSL-N150
Description
User Manual
