Removing and Replacing Power Supplies

WARNING: Avoid electrical shocks. To avoid electrical shock, do not open the power supplies. There
are no user-serviceable parts inside.
To avoid electrical shock and harm to your eyes by laser light, do not open the DVD laser module. The
laser module should be serviced by service personnel only. Do not attempt to make any adjustment to the
laser unit. Refer to the label on the DVD for power requirements and wavelength. This product is a class I
laser product.
CAUTION: Before removing a power supply, make sure the second power supply is functioning
properly. The two green LEDs inside the supply must both be lit on the second supply before you
can safely remove the failed power supply.
The power supplies in the zx2600 and zx6000 servers are hot-swappable; that is, if one power
supply stops working or exhibits voltage problems, the remaining supply can support the server
until the failed unit is replaced. On servers with two power supplies, one power supply can be
removed and replaced without turning the server off.
Removing a Power Supply
To remove a power supply, follow these steps:
1. Remove the front bezel from the server.
2. Press the power supply retaining clip to unlatch the power supply release lever.

Releasing the Power Supply Retaining Clip

3. Depress the power supply release lever and slide the power supply out of the server.
HP Integrity rx2600 server and HP workstation zx6000 Operation and Maintenance Guide
Removing and Replacing Components
73
