HP EliteBook 2570p Maintenance And Service Manual page 44

Spare part number
628824-001
631954-001
632417-001
632419-001
632421-001
632423-001
633252-001
634400-001
634925-001
641369-001
651376-001
651377-001
651378-001
651380-001
651381-001
651382-001
651384-001
652972-001
655792-001
665733-001
669832-001
670034-001
36 Chapter 3 Illustrated parts catalog
Description
Modem module (56k v.92 MDC data/fax, does not include cable)
NOTE: The modem module does not include a cable. The modem module cable is included in the
Cable Kit, spare part number 651384-001. See
information.
Intel Centrino Advanced-N 6205 WLAN module
3-cell, 31-Wh, 2.80-Ah, Li-ion battery
6-cell, 55-Wh, 2.80-Ah, Li-ion battery
6-cell, 62-Wh, 2.80-Ah, Li-ion battery
9-cell, 100-Wh, 3.00-Ah, Li-ion battery
750-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket, hard drive connector
adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 651380-001.
HP un2430 EV-DO/HSPA Mobile Broadband Module
500-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket, hard drive connector
adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 651380-001.
4-GB memory module (PC3, 12800, 1600-MHz)
Plastics Kit (includes ExpressCard slot space saver, optical drive bay space saver, RJ-11 jack plug)
NOTE: See Plastics Kit on page 33
Speaker assembly (includes cable)
Fan (includes cable)
Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector adapter, and screws)
Bracket Kit (includes top cover left and right brackets)
Rubber Kit (includes base enclosure rubber bumpers)
Cable Kit (includes Bluetooth module cable and modem module cable)
NOTE: See Cable Kit on page 31
2-GB memory module (PC3, 12800, 1600-MHz)
Bluetooth module 4.0 EDR
NOTE: The Bluetooth module does not include a cable. The Bluetooth module cable is included in
the Cable Kit, spare part number 651384-001. See
information.
RTC battery (includes cable and double-sided adhesive)
Broadcom 43228 802.11abgn 2×2 Wi-Fi Adapter
8-GB memory module (PC3, 12800, 1600-MHz)
Cable Kit on page 31
for more Plastics Kit information.
for more Cable Kit information.
Cable Kit on page 31
for more Cable Kit
for more Cable Kit
