Table 2
Clearance 2/20, 4/40, and 6/60 series stand-alone configurations — located on or
below a table:
Back:
Front:
Sides:
2/20, 4/40, and 6/60 series rackmounted configurations:
Back:
Front:
Sides:
Height:
8/80 and 10/100 series tape libraries
Back:
Front:
Sides:
Floor rating For 8/80 and 10/100 series tape libraries only.
A fully loaded library can weigh up to 325 kg (715 lbs). Each caster supports
up to 96 kg (213 lbs). To support the weight exerted on the floor by the casters,
the floor rating must meet or exceed 1,694 kg per square meter (347 lbs per
square foot).
Tip rating For 8/80 and 10/100 series libraries only.
Do not tip the library more than 10°. Ensure that the location for the library has
a level surface.
Chapter 1
Location Criteria
56 cm (22 in) for cooling and service.
86 cm (34 in) for operator access.
56 cm (22 in) for removal of the external cover.
61 cm (24 in) minimum to allow adequate room for service
access.
86 cm (34 in) for operator access.
56 cm (22 in) minimum
For ease of use and optimum safety, the top of the library
should be mounted approximately 120 cm (48 in) above the
floor.
56 cm (22 in) minimum
191 cm (75 in) minimum
5 cm (2 in) minimum
Choosing a Location 15
