Crestron TPMC-12L
Operations Guide – DOC. 6686C
TPMC-CH-IMC Interface Module
For networks without CAT5 audio and video, the TPMC-CH-IMC Interface Module
(as well as a 15 foot "triamese" interface cable) is included to convert unbalanced
video sent over coax cable and balanced/unbalanced audio sent over shielded,
twisted-pair wiring to Crestron Certified Wire for connection to the touch screen.
NOTE: The TPMC-CH-IMC is not for use with QuickMedia.
NOTE: Audio and video wiring between the touch screen and module may be as
long as 500 feet (152 meters) for component video or 750 feet (229 meters) for
composite and S-video. However, the length of Cresnet cable must account for limits
based upon the touch screen power requirements. Refer to the latest version of the
TPMC-CH-IMC Interface Module Operations Guide (Doc. 6345) and "Network
Wiring" on page 13.
QM-TX QuickMedia Transmitter
The QM-TX QuickMedia Transmitter (sold separately) can be used to connect a
video or audio source to a QuickMedia network without a locally available QM
transmitter (such as the QM-WMC).
The QM-TX accepts composite video, S-video, component video and audio signals.
These signals are converted to the QuickMedia standard and fed over a CAT5E or
CAT6 cable to a QM receiver (such as the TPMC-12L). All signal routing occurs
automatically under the command of the control system.
For more information, refer to the latest version of the QuickMedia Transmitter:
QM-TX Operations Guide (Doc. 6334).

Recommended Cleaning

Keep the surface of the touch screen free of dirt, dust or other materials that could
degrade optical properties. Long-term contact with abrasive materials can scratch the
surface, which may detrimentally affect image quality.
For best cleaning results use a clean, damp, non-abrasive cloth with any
commercially available non-ammonia glass cleaner. Bezels may not provide a
complete watertight seal. Therefore, apply cleaning solution to the cloth rather than
the surface of the touch screen. Wipe touch screen clean and avoid getting moisture
beneath the bezels.
®
Isys 12" Wall Mount Touch Screen
®
12" Wall Mount Touch Screen: TPMC-12L • 43
