- Page 2 This document was prepared and written by the Marketing Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
- Page 3 All brand names, product names and trademarks are the property of their respective owners. ® ® Windows and Windows XP are registered trademarks of Microsoft Corporation in the United States and other countries. ©2006 Crestron Electronics, Inc.
-
Page 5: Table Of Contents
Crestron Contents Crestron Quick Guide to Touchpanel Connections Introduction ... 1 TPMC-15 and TPMC-17 Hookup Details ... 2 RS-232 ... 2 ETHERNET (LAN) ... 3 USB... 4 PWR (Power) ... 4 PHONE ... 5 PC CARD ... 5 NET ... 5 CH (CH versions only) ... - Page 6 TPS-15 Application with CNX-BIPAD8 and CNX-PVID8X3 ... 27 TPS-17 Application – with Intercom, Audio Distribution, Video Distribution, Security, and Phone System ... 28 TPS-2000L Hookup Details ... 29 TPS-3000 and TPS-4000 Hookup Details... 31 HEADPHONES ... 31 AUDIO... 32 RS-232 ... 32 NET/VIDEO...
-
Page 7: Crestron Quick Guide To Touchpanel Connections
This document contains detailed hookup information for the current line of Crestron touchpanels. Additional information may be found in the specific operations manual for each product, refer to the Crestron website (www.crestron.com). CAUTION: Do not apply excessive pressure to the touchscreen display during handling. -
Page 8: Tpmc-15 And Tpmc-17 Hookup Details
N/C (Not connected) In the event that modular cables or an RJ-11 to DB9F adapter is not available, the following diagram provides information so that the cable can be fabricated on site. Doc. 4903 DESCRIPTION Crestron Quick Guide to Touchpanel Connections Crestron... -
Page 9: Ethernet (Lan)
(green LED indicates network speed, yellow LED indicates Ethernet activity). This connector provides an Ethernet 10baseT/100baseTX, full duplex, IEEE 802.3U compliant network connection. Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections Network Connector Pinout SIGNALS TX +... -
Page 10: Usb
Power Requirements: 101 Watts (8.4 Amp @ 12 VDC) From supplied power supply. CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to do so could cause equipment damage or void the Crestron warranty. Doc. 4903 DESCRIPTION... -
Page 11: Phone
The TPMC-15 and TPMC-17 do not use, or supply power to the 24 VDC Cresnet connection. NOTE: The TPMC-15 and TPMC-17 are only compatible with 2-Series control systems. Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections Doc. 4903... -
Page 12: Ch (Ch Versions Only)
Quick Guide to Touchpanel Connections CH (CH versions only) CH versions of the TPMC-15 and TPMC-17 feature two video input ports to connect to a Crestron CNX- PVID device (or any Crestron CAT5 video source such as CNXRMC, CNXRMCLV, C2N-IVDS) and one... -
Page 13: Video Connection Example - Balanced S-Video From Cnx-Pvid
WIRE COLORS WHITE/ORANGE ORANGE WHITE/GREEN BLUE WHITE/BLUE GREEN WHITE/BROWN BROWN Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections Balanced S-Video from CNX-PVID TO PIN QM RGB (568B) ASSIGNMENT - RGB Red + RGB Red - RGB Green... - Page 14 #2 is capable of the following signals, resolutions, and cable lengths: QM Input # 2 Maximum Cable Length SIGNAL TYPE Video/S-video Component Component Component * Using CresCAT-QM cable, available from Crestron. Using other cable may vary performance. Doc. 4903 RESOLUTION MAXIMUM CABLE 480i 480p...
-
Page 15: Quickmedia Installation Notes
The total accumulated skew from QM transmitter to QM receiver must not exceed 15 ns (nanoseconds). Crestron recommends a cable with a rating of less than or equal to 15 ns over its entire length. For example, if using a cable... -
Page 16: Tps-12G-Qm And Tps-15G-Qm Interface: Quickmedia Device
Quick Guide to Touchpanel Connections Crestron TPS-12G-QM and TPS-15G-QM Interface: QuickMedia Device Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 17: Tps-12G-Qm And Tps-15G-Qm Interface: Extended Application
Crestron Quick Guide to Touchpanel Connections TPS-12G-QM and TPS-15G-QM Interface: Extended Application Dual Video/RGB Windows and Audience Presentation Crestron Quick Guide to Touchpanel Connections Doc. 4903... -
Page 18: Tps-12G-Qm And Tps-15G-Qm Kitchen Control Application
Quick Guide to Touchpanel Connections Crestron TPS-12G-QM and TPS-15G-QM Kitchen Control Application TPS-12G-QM or TPS-15G-QM Podium Application – with QM-MD7X2 Switcher for Multiple AV Inputs Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 19: Tps-12, Tps-15, Tps-17 Hookup Details
Crestron TPS-12, TPS-15, TPS-17 Hookup Details RS-232 Refer to page 2 for details. Refer to page 3 for details. Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections Doc. 4903... -
Page 20: Net
TPS-15 = 65 W (2.7 A @ 24 V) TPS-17 = 74 W (3.08 A @ 24 V) Crestron recommends an independent power supply for these touchpanels. USB Pinouts DESCRIPTION +5 VDC Data - Data + Ground Crestron Quick Guide to Touchpanel Connections Crestron... -
Page 21: Memory Expansion
QM IN (QuickMedia Input) The eight-pin RJ-45 QuickMedia transport port accepts Crestron Certified Wiring carrying audio, video, and microphone signals. The QM input port conforms to the 568B wiring standard. Refer to the following table for connector pinouts. -
Page 22: Video In
CNX-PVID or the TPMC-CH-IMC interface module. This port provides component, composite or S-video balanced input to the touchpanel over Crestron Certified Wiring. Description of the pinouts is shown in the following table. A cable for this connection is provided with the touchpanel. -
Page 23: Audio I/O
This 8-pin RJ-45 connector provides connectivity to the CNX- BIPAD or with the TPMC-CH-IMC interface module. This port uses Crestron Certified Wiring and provides audio input to the touchpanel and microphone output from the touchpanel. A description of the pinouts is shown in the following table. -
Page 24: Tpmc-Ch-Imc Touchpanel Interface Hookup Details
Quick Guide to Touchpanel Connections Crestron TPMC-CH-IMC Touchpanel Interface Hookup Details Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 25: Net
The 5-position mini- terminal block connector mates with the included connector and provides balanced and/or unbalanced microphone output. Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections AUDIO IN Pinouts Left Positive Left Negative Ground Right Positive Right Negative... -
Page 26: Video (To Panel)
- Chrominance WIRE COLORS (568A) WHITE/GREEN GREEN WHITE/ORANGE BLUE WHITE/BLUE ORANGE WHITE/BROWN BROWN Crestron Quick Guide to Touchpanel Connections Crestron COMPONENT + PB + PR - PR - PB AUDIO I/O + Mic Left Out - Mic Left Out + Mic Right Out... -
Page 27: Tpmc-Ch-Imc Interface Connections For Tps-12, Tps-15, & Tps-17
500 feet Audio 1000 feet (balanced) TPMC-CH-IMC Interface Connections for TPS-12, TPS-15, and TPS-17 Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections • The maximum distance for CAT5 audio is limited to approximately 15 feet when connecting the AUDIO OUT port to a device with an unbalanced input. -
Page 28: Quickmedia Interface Connections For Tps-12, Tps-15, & Tps-17
Quick Guide to Touchpanel Connections Crestron QuickMedia Interface Connections for TPS-12, TPS-15, and TPS-17 Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 29: Balanced Av Distribution Connections For Tps-12, Tps-15, & Tps-17
Crestron Quick Guide to Touchpanel Connections Balanced AV Distribution Connections for TPS-12, TPS-15, and TPS-17 (CNX-BIPAD8 and CNX-PVID8) Crestron Quick Guide to Touchpanel Connections Doc. 4903... -
Page 30: Balanced Cat5 Av Distribution Connections For Tps-12, Tps-15
Quick Guide to Touchpanel Connections Crestron Balanced CAT5 AV Distribution Connections for TPS-12, TPS-15, and TPS-17 (C2N-IADS30X24 and C2N-IVDS24X24) Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 31: Tps-12, Tps-15, And Tps-17 Applications
Crestron Quick Guide to Touchpanel Connections TPS-12, TPS-15, and TPS-17 Applications TPS-12, TPS-15, or TPS-17 Family Room Application – with Audio and Video Distribution Crestron Quick Guide to Touchpanel Connections Doc. 4903... -
Page 32: Tps-12, Tps-15, Or Tps-17 Application - Podium Control With Qm-Md4X2 Switcher For Dual Av Input
Quick Guide to Touchpanel Connections Crestron TPS-12, TPS-15, or TPS-17 Application – Podium Control with QM-MD4X2 Switcher for Dual AV Input Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 33: Tps-15 Application With Cnx-Bipad8 And Cnx-Pvid8X3
Crestron Quick Guide to Touchpanel Connections TPS-15 Application with CNX-BIPAD8 and CNX-PVID8X3 Crestron Quick Guide to Touchpanel Connections Doc. 4903... -
Page 34: Tps-17 Application - With Intercom, Audio Distribution, Video Distribution, Security, And Phone System
Quick Guide to Touchpanel Connections Crestron TPS-17 Application – with Intercom, Audio Distribution, Video Distribution, Security, and Phone System Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 35: Tps-2000L Hookup Details
BALANCED AUDIO & VIDEO column centered in the table. Balanced video format is typically used when distributing video via CAT 5 (i.e., from a Crestron CNX-PVID8x3 or 8x4). To obtain unbalanced audio or video, attach jumpers to designated pins and make connections as described in the three right-most columns. - Page 36 AUDIO IN AUDIO OUT Audio In + Audio Ground NOTE: MIC Out + Jumper pins 2 & 3 MIC Ground Crestron Quick Guide to Touchpanel Connections Crestron UNBALANCED VIDEO NOTE: Jumper pins 6 & 8 Video Ground Video + Video Ground...
-
Page 37: Tps-3000 And Tps-4000 Hookup Details
Crestron TPS-3000 and TPS-4000 Hookup Details NOTE: TPS-3000 and TPS-4000 include a TPS-IMPC Interface Module for system connection. Refer to page 33 for hookup details. NOTE: The audio connectors are color-coded blue. Hardware connections for the TPS-3000 and TPS-4000 (Back of the base is shown) -
Page 38: Audio
CAUTION: The 10-pin RJ-45 connector cable supplied by Crestron is a custom cable and is the only one that should be used. The end of the cable has a metal shield that is required to protect the equipment. -
Page 39: Tps-Impc Hookup Details
TPS-IMPC Hookup Details The TPS-IMPC is designed specifically to serve as an interface module for the Crestron tilt touchpanel. It is supplied with every Isys includes audio capability. A network connector and video input connectors are located on one side of the unit. The opposite side offers audio input, microphone output (600 Ohms balanced and 300 Ohms unbalanced MIC OUT), and audio and network/video connections to the touchpanel. - Page 40 Quick Guide to Touchpanel Connections Crestron TPS-IMPC Hookup Doc. 4903 Crestron Quick Guide to Touchpanel Connections...
-
Page 41: Ntsc/Pal Video
2 video card in a TPS-5000 or TPS-6000 touchpanel to display video. Consult the latest revision of the TPS-3000 Operations Guide (Doc. 6076) or TPS-VID-1/2 Operations & Installation Guide (Doc. 6059) for details. Use either the two BNC connectors or the six-pin connector for twisted pair wiring when connecting a video source. -
Page 42: Net
Cresnet power connection on the NET connector is not required to display video on the touchpanel. CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to do so could cause equipment damage or void the Crestron warranty. CAUTION: If power is provided to the TPS-IMPC from the +24VDC on a Cresnet connector or the PW-2420RU, power must not be applied to the power input on the touchpanel base. -
Page 43: Net/Video (To Panel)
The 10-pin RJ-45 net/video connector cable supplied by Crestron is a custom cable and is the only one that should be used. The end of the cable has a metal shield that is required to protect the equipment. Using non-Crestron cables will result in damage to the product. -
Page 44: Audio (To Panel)
Quick Guide to Touchpanel Connections AUDIO (To Panel) This 8-pin RJ-45 mates with the TPS-3000, TPS-5000, or TPS-6000 touchpanel. The 8-pin audio cable assembly is supplied. Even though the 10-pin net/video cable may fit into the port, do not use it. -
Page 45: Audio Input
MIC OUT Pinouts For additional information, refer to the latest version of the TPS-IMPC Operations Guide (Doc. 6162), which is available from the Crestron website (http://www.crestron.com/manuals). Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections... -
Page 46: Tps-3100L Hookup Details
Quick Guide to Touchpanel Connections Crestron TPS-3100L Hookup Details Hardware Connections for the TPS-3100L (Back of the Unit is Shown) Doc. 4903 Crestron Quick Guide to Touchpanel Connections... -
Page 47: Net
Pins Y and Z provide communications (data) MIC OUT This 3-position mini-terminal block connector provides balanced line level microphone output with AGC. MIC Pinouts PIN # Crestron Quick Guide to Touchpanel Connections Quick Guide to Touchpanel Connections DESIGNATION DESCRIPTION Mic Output (Positive) Mic Output (Negative) -
Page 48: Audio Input
DESIGNATION Shield Right Input (Positive) Right Input (Negative) Left Input (Positive) Left Input (Negative) Shield DESIGNATION Ground Right Input (Positive) Right Ground Left Input (Positive) Left Input Ground Ground Crestron Quick Guide to Touchpanel Connections Crestron AUDIO INPUT DESCRIPTION DESCRIPTION... -
Page 49: Ntsc/Pal Input
Both sets of inputs support both NTSC and PAL formats. Balanced video format is typically used when distributing video via CAT 5 (i.e., from a Crestron CNX-PVID8x3 or 8x4). Unbalanced video is typically used when distributing video via coaxial cable. -
Page 50: Tps-4L Hookup Details
• Pins 24 and G provide 24 VDC and ground. • Pins Y and Z provide communications (data) Doc. 4903 SIGNALS TX + TX - RC + Crestron Quick Guide to Touchpanel Connections Crestron SIGNALS RC -... -
Page 51: Cresnet Touchpanel Power Q&A
Cresnet (and other) cable? The higher resolution, brightness, and added capabilities of the new Crestron touchpanels have come at a price. More power is needed to drive these devices. This is especially true for the wired “TPMC”... - Page 52 75 Watt power supply to a specific touchpanel. L < 40,000/(PF x R) Where: “L”= length in feet, “PF”= Crestron ‘Power Factor’, “R”= Cable “Resistance” Refer to the following table for maximum cable lengths.
-
Page 53: Further Inquiries
Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. - Page 54 Crestron Electronics, Inc. Quick Guide to Touchpanel Connections 15 Volvo Drive Rockleigh, NJ 07647 Doc. 4903 Tel: 888.CRESTRON 07.06 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
