38 • Isys
12" Wall Mount Touch Screen: TPMC-12L
Right click: simulates right-click of mouse
Size: toggles on-screen keyboard size (small, medium, large)
Keyboard translucence down: decreases keyboard translucence
Keyboard translucence up: increases keyboard translucence
On-Screen Keyboard
The initial position of the on-screen keyboard is determined by the VT Pro-e
program or SIMPL Windows settings. The on-screen keyboard will default to its
largest size.
In use, when the on-screen keyboard is moved and/or resized and then closed, it will
re-open in the same position it was in and at the same size it was when closed. This
position and size will remain in memory until the touch screen is re-booted or it is
re-set by the SIMPL Windows program. After reboot, the position of the on-screen
keyboard will revert to the defaults set in the VT Pro-e or SIMPL Windows program.
The size will revert to the largest as determined by the firmware installed in the
touch screen.
Exit the on-screen keyboard by selecting by touching the "X" close button in the
upper right corner of the keyboard window. If the Keyboard button on the start
menu is still visible, you can also touch it to exit the keyboard.
Screen Brightness Details
The Screen Brightness can be varied from 0 to 100. To increase the brightness, touch
Up. To decrease the brightness, touch Down.
Hard Button Feedback Details
The Hard Button Feedback section of the setup menu provides visual feedback for
all hard button presses. Pressing any of the hard buttons (except Reset) will result in
its corresponding icon on the screen illuminating in bright green
Ethernet Status Details
The Ethernet Status section of the setup menu provides a Link Status light to indicate
an Ethernet connection and displays the current IP and MAC addresses.
