Crestron TPMC-12L
Show Keyboard
Operations Guide – DOC. 6686C
"Message Popup Configuration" Window
There are three types of Network popup messages. Following are definitions of each
message type:
•
Connected: A green popup message appears when the touch screen is
connected to the control system.
•
Checking Connection: A yellow popup message appears when the touch
screen is experiencing network issues.
•
Disconnected, Trying to Reconnect...: A red popup message appears
when the touch screen loses connection with the control system.
A control for popup message Translucence is also provided. Translucence ranges
from 25% to 100%, with a default value of 90%.
The Default button restores the original Screen Position and Translucence settings,
as well as enabling display of Network messages. A Test Message button lets you
see the changes to popup message position and translucence. Touch Close to close
the popup window.
NOTE: The default value for Screen Position is Lower Left.
Touch the Keyboard button to display the on-screen keyboard.
The on-screen keyboard can be used in an identical manner to a physically connected
keyboard. It can be used in any of the embedded applications, for example, to enter a
web address or to enter data into a spreadsheet, etc.
The on-screen keyboard also has a few special keys:
Volume down
Volume up
®
Isys
12" Wall Mount Touch Screen
®
12" Wall Mount Touch Screen: TPMC-12L • 37
