Scrolling Screen Painter; Properties Of Secondary Windows - Avaya Call Management System Custom Reports

Using Screen Painter editing tools
Screen Painter size and cursor position

Scrolling Screen Painter

Screen Painter scrolls automatically when the cursor touches the left, right, top, or bottom
border. Screen Painter scrolls one column or one line at a time when you use the arrow
keys, but scrolls eight columns at a time when you use
scrolling beeps when the 132nd column is displayed. Left scrolling beeps when the first
column is displayed. Down scrolling stops when the 25th line is displayed. Up scrolling
stops when the top line is displayed again.

Properties of secondary windows

For most tasks on Screen Painter, you must complete a secondary window. These
secondary windows pop up after you select an action list option. Some secondary windows
automatically close when you are finished entering data and select an action list option.
However, for some secondary windows, you must press the Exit screen-labeled key
(screen-labeled key)
If you use the
Screen Painter, the secondary window remains open. However, until you close the
secondary window, Screen Painter is locked and you cannot enter text or select any other
action list options.
44 Avaya CMS Custom Reports
20 lines
displayed
Vertical area
available = 25 lines
to close the window and return to Screen Painter.
screen-labeled key to leave a secondary window and return to
Current
54
columns
displayed
Horizontal area
available = 132 columns
Cursor position
for horizontal scrolling. Right
Tab
