Digital Performer 5/6 - Zoom R16 Operation Manual

Digital Performer 5/6

Control surface setup
1
Launch the Audio MIDI Setup
application. (/Applications/
Utilities).
2
Click the MIDI Devices tab and
confirm that "ZOOM R16" is
displayed.
3
Click "Add Device."
A "new external device" will be added.
4
Double-click the "new external
device" to open its "Information"
window.
5
Enter the name "R16" in the
"Device Name" field.
6
Click and drag the downward
arrow of the original "ZOOM
R16" icon and connect it to the
downward arrow of the "R16"
icon that you added.
Use same method to connect the upward arrows.
7
Start Digital Performer.
8
Select "Control Surface Setup"
from the "Setup" menu.
The Control Surface window will open.
9
Click the "+" icon in the Control
Surface window and select
"Mackie Control" from the
"Driver" pull-down menu.
1 0
Select "Mackie Control" from the
"Unit" pull-down menu that will
be displayed at bottom.
1 1
Select "R16" from the "MIDI"
pull-down menu of the Control
Surface window and select [R16-
1] from the menu list.
1 2
Click the "OK" button.
The above procedures are for Digital Performer 5.
The names of the menus might be different in a
different version of Digital Performer.
Please refer to the manual for the version of Digital
Performer that you are using for details.
Function key setup
The default functions are allocated in Digital Performer
and you cannot change these functions.
F1 [AUTO PUNCH IN/OUT]:
F2 [A-B REPEAT]: Selects NO in dialog boxes
F3 MARKER [|<<]: Creates track groups/groups
F4 MARKER [>>|]: Releases pause and stop of
track group/group function
F5 [MARK/CLEAR]: Releases track group/group
function
Refer to sections about Mackie Control dialog boxes and
track groups in the Digital Performer manual.
Samplitude
· Mackie Control is a registered trademark of LOUD
Technologies Co.
· Other trademarks and registered trademarks
in this document belong to their owners.
Selects YES in
dialog boxes
32
