Front Cover Door Removal/Replacement
The front door is required for regulatory compliance. Replace the door immediately if it is
damaged. The door must be replaced by a trained service representative.
The disk enclosure will need to be powered down to complete this procedure. Turning the
power off and disconnecting power and SCSI cables eliminates the possibility of
inadvertently pulling out live cables and causing an unplanned shutdown when you move
the disk enclosure forward in the rack.
To replace the front door, complete the following steps:
1.
Loosen the enclosure from the rack and slide it forward 2 to 3 inches in the rack. See
"Disk Enclosure SC10" on page
1.
With the door closed, remove two screws from each hinge block (C in
2.
Pull the hinge blocks straight out from the sides of the enclosure, letting the latch hold
the door in place.
3.
Supporting the door with one hand, unlock (see
Internal Disk Enclosure Assemblies
308
304.
Figure
Figure
99).
97) and remove the door.
