1. Open the disk enclosure door.
2. Put on the ESD strap (provided with the accessories) and insert the end into the ESD
plug-in (D in Figure
Disks are fragile. Handle them carefully.
C
AUTION
3. Remove the bagged disk from the disk pack.
Do not touch exposed circuit board side of the disk module.
C
AUTION
4. Remove the disk from the ESD bag, grasping the disk by its handle (B).
5. Using a pencil, mark an "X" on the Slot Location Map label (A in
the top of the disk module. This mark identifies the disk slot the disk module should be
installed in case it is removed. It is important to return a disk to its same location to
maintain disk module addressing used by some FC60 software applications.
Figure 52
Disk Module Slot Location Map Label
Installing the Disk Enclosures
134
51) near the upper left corner of the disk enclosure.
Figure 52), located on
Do Not Touch
