Option
-fw
-CLI
-m <mode>
56 Replication commands
Description
Used when displaying the WWN setting (defined by "50060E80+RAID Type,Serial#,Port#)) to the
port instead of a port name. If this option is specified with the "-fe" option at the same line, then
"LUN WWN" appears as shown below. If WWN is not computed, then "Unknown" appears (For
example, SCSI).
Display example:
# pairdisplay -g PG01 -fw
Group PairVol(L/R) (WWN, LU-M),Seq#,LDEV#.P/S,Status, Seq#,P-LDEV# M
PG01 ora01(L) (500060e804f42001, 3-0) 62496 67. P-VOL COPY,62496 69 -
PG01 ora01(R) (500060e804f42001, 5-0 )62496 69. S-VOL COPY,----- 67 -
PG01 ora02(L) (500060e804f42001, 4-0 )62496 68. P-VOL COPY,62496 64 –
PG01 ora02(R) (500060e804f42001, 6-0 )62496 64.S-VOL COPY,----- 68 –
Display example:
# pairdisplay -IH -g PG01 -CLI -l -fwe
Group PairVol L/R WWN LU Seq# LDEV# P/S Status Fence Seq#
P-LDEV# M CTG JID AP EM E-Seq# E-LDEV# LUN-WWN
PG01 oradb01 L 500060e804fa0f01 1 64015 1 1 P-VOL PAIR ASYNC 62496
1 1 - 5 - 1 - - - 60060e8005fa0f000000fa0f0000000b
PG01 oradb02 L 500060e804fa0f01 2 64015 12 P-VOL PAIR ASYNC 62496
12 - 5 - 1 - - - 60060e8005fa0f000000fa0f0000000c
Used when specifying display for command line interface (CLI). This option displays to the same
position that defined number of columns, and displays one header. The delimiters between columns
are displayed as spaces or hyphens (-).
Display example:
Group PairVol L/R Port# TID LU-M Seq# LDEV# P/S Status Seq# P-LDEV# M homrcf1 deva0 L CL1-D
3 5 0 30053 271 P-VOL PAIR 30053 263 - homrcf1 deva1 L CL1-D 3 5 1 30053 271 SMPL - - - -
homrcf1 deva2 L CL1-D 3 5 2 30053 271 SMPL - - - -
Used when displaying a paired status of each mirror descriptors for the specified pair logical volume,
and used for paired status indication of the cascading volume. The <mode> option can be designated
"cas" or "all" :
The "cas" option is used when displaying a paired status of specified group that is registered to
the mirror descriptor (MU#) on the cascading configuration file.
The "all" option is used when displaying a paired status of all mirror descriptors (MU#).
This option (-m <mode>) is not affected with command execution environment (Continuous Access
Synchronous and Business Copy), and displays the paired status. This option cannot be specified
with the -FHORC/-FMRCF option on the same command line.
