- ERR_05: this means the status of "Resource Shortage" in path.
- ERR_06: this means the status of "Serial Number Mismatch" in path.
- ERR_10: this means the status of "Invalid Port" in path.
- ERR_80: this means the status of "RCU Port Number Mismatch" in path.
- ERR_81: this means the status of "RCU Port Type Mismatch" in path.
- ERR_82: this means the status of "Communication Failed" in path.
-SSIDs
This displays the SSIDs (hexadecimal) setting to RCU.
If CU free is specified for RCU, "-" is displayed.

raidcom modify rcu

Sets the control parameters to CU that is specified using two way.

Syntax

raidcom modify rcu -cu_free <serial#> <id> <pid> -rcu_option <mpth> <rto> <rtt>

Options and parameters

Option
-cu_free <serial><id><pid>
-rcu_option <mpth> <rto>
<rtt>

Examples

For the RCU for which the product number; 64034, the RAID type: P9500 and the path ID: 1 are
set, setting the options: the minimum number of paths <mpth>-4, RIO MIH time<rto>15 seconds,
and Roud trip time 20 are set.
raidcom modify rcu -cu_free 64034 R700 1 -rcu_option 4 15 20

raidcom add rcu_path

Adds logical paths to RCUs.
This command is executed asynchronously with the command input. Check the completion of this
process on the raidcom get command_status command.
Syntax
raidcom add rcu_path -cu_free <serial#> <id> <pid> -mcu_port <port> -rcu_port <port>
Description
-cu_free <serial#> <id> <pid>
This parameter is used to specify CU free that is specified by Serial#, id#, pid#.
< id > is used to set RAID Type, and it can be specified the following strings.
XP12000 Disk Array/XP10000 Disk Array:R500, XP24000/XP20000 Disk Array:R600,
P9500:R700
<pid> is used to set the path group ID (1-255).
This parameter is used to specify CU control parameters.
<mpth> is used to set the number of path as minimum (1–8).
<rto> is used to set the timeout value (10–100) (second) for RIO (Remote IO) setting
between MCU and RCU.
<rtt> is used to set the round trip time value (1–500) (millisecond) between MCU and
RCU.
raidcom modify rcu 181
