Setting Up and Configuring the Router
Status
Cisco RVS4000 Security Router with VPN Administrator Guide
DNS 1-2 Displays the DNS (Domain Name System) IP addresses currently used
by this Gateway.
IP Conntrack Click this button to display the IP Conntrack window.
IP Conntrack
The IP Conntrack (Connection Tracking) window displays information about TCP/
UDP connections, such as source and destination IP address and port number
pairs (known as socket pairs), protocol types (TCP/UDP/ICMP), connection state
and timeouts. To see more information, click Next Page or Previous Page, or
select the page from the Go to Page drop-down menu. To see the latest
information, click Refresh. Click Close to return to the Status > Gateway window.
Status > Gateway > IP Conntrack
