Getting Started with the RVS4000 Router

Configuring the Router

STEP 4
STEP 5
STEP 6
STEP 7
Configuring the Router
NOTE
STEP 1
STEP 2
STEP 3
Cisco RVS4000 Security Router with VPN Administrator Guide
Power on the cable or DSL modem.
Connect the power adapter to the router's Power port and plug the other end into
an electrical outlet.
The Power and Internet LEDs on the front panel lights up green as soon as the
power adapter is connected.
Power on the PCs.
The router hardware installation is now complete.
To configure the RVS4000, connect a PC to the router and launch the configuration
utility.
Before setting up the router, make sure your PCs are configured to obtain an IP (or
TCP/IP) address automatically from the router.
Launch a web browser, such as Internet Explorer or Mozilla Firefox.
In the Address field enter http://192.168.1.1 and press Enter.
In the User Name and Password fields, enter admin. The default user name and
password are admin.
