To set up LDAP:
Install a certificate on the Windows Active Directory server for LDAP. Create a user in Microsoft Active
1.
Directory server. For instructions on how to create a user, refer to
documentation to create a user in your Active Directory.
2. Create a group name that uses the switch's role name so that the Active Directory group's name is the
same as the switch's role name.
3. Associate the user to the group by adding the user to the group. For instructions on how to create a user
refer to www.microsoft.com
4. Add the user's Administrative Domains to the CN_list by editing the adminDescription value.
This will map the admin domains to the user name. Multiple admin domains can be added as a string
value separated by the underscore character ( _ ).
To create a user:
To create a user in Active Directory, refer to
special attributes.
To create a group:
To create a group in Active Directory, refer to
need to verify that the group uses the following attributes:
• The name of the group has to match the RBAC role.
• The Group Type must be Security.
• The Group Scope must be Global.
To assign the group (role) to the user:
To assign the user to a group in the Active Directory, refer to
documentation. You will need to verify that the user has the following attributes:
1. Update the memberOf field with the login role (Root, Admin, SwitchAdmin, User, etc.) that the user must
use to log in to the switch.
From the Windows Start menu, select Programs> Administrative Tools> ADSI.msc
2.
ADSI is a Microsoft Windows Resource Utility. This will need to be installed to proceed with the rest of
the setup. For Windows 2003, this utility comes with Service Pack 1 or you can download this utility
from the Microsoft website.
3. Go to CN=Users0
Right click on select Properties. Click the Attribute Editor tab.
4.
Double-click the adminDescription attribute.
5.
This opens the String Attribute Editor dialog box.
6. Enter the value for the admin domains separated by an underscore ( _ ) into the Value field.
Example
adlist_0_10_200_endAd
Home Admin Domain (homeAD) for the user will be the first value in the adlist (Admin Domain list). If a
user has no values assigned in the adlist attribute, then the homeAD '0' will be the default
administrative domain for the user.
NOTE: You can perform batch operations using the Ldifde.exe utility. For more information on importing
and exporting schemas, refer to your Microsoft documentation or visit www.microsoft.com.
