Table 98 Command checklist for configuring FCIP links (continued)
Step
3. If a VEX port is to be implemented,
configure the appropriate virtual port as
a VEX_Port.
4. Configure the IP interface for both
ports of a tunnel.
5. Verify the IP interface for both ports
of a tunnel.
6.Create one or more IP routes
connecting the IP interfaces across the IP
network.
7. Create ARP entry for the IP interface if
VLAN tagging is to be implemented.
(For IPv4 only, not required for IPv6).
8.Test IP connectivity between the local
Ethernet interface (ge0 or ge1) and a
destination IP address.
9. Configure FCIP tunnels.
10. If you are implementing FICON
emulation, configure FICON emulation.
1 1. If you are implementing FTRACE,
configure FTRACE.
12. Verify FCIP tunnels.
13. Enable the ports.

Configuring IPSec

IPSec requires predefined configurations for IKE and IPSec. You can enable IPSec only when these
configurations are well-defined and properly created in advance.
The following describes the sequence of events that invokes the IPSec protocol.
1. Traffic from an IPSec peer with the lower local IP address initiates the IKE negotiation process.
2. IKE negotiates SAs and authenticates IPSec peers, and sets up a secure channel for negotiation of
phase 2 (IPSec) SAs.
3. IKE negotiates SA parameters, setting up matching SAs in the peers. Some of the negotiated SA
parameters include encryption and authentication algorithms, Diffie-Hellman key exchange, and SA
lifetimes.
4. Data is transferred between IPSec peers based on the IPSec parameters and keys stored in the SA
database.
5. IPSec tunnel termination. SA lifetimes terminate through deletion or by timing out.
All of these steps require that the correct policies have been created. Because policy creation is an
independent procedure from FCIP tunnel creation, you must know which IPSec configurations have been
created. This ensures that you choose the correct configurations when you enable an IPSec tunnel.
The first step to configuring IPSec is to create a policy for IKE and a policy for IPSec. Once the policies
have been created, you assign the policies when creating the FCIP tunnel.
IKE negotiates SA parameters and authenticates the peer using the preshared key authentication method.
Once the 2 phases of the negotiation are completed successfully, the actual encrypted data transfer can
begin.
Command
portcfgvexport
portcfg ipif
portshow ipif
portcfg iproute
portcfg arp add
portcmd - -ping
portcfg fciptunnel
portcfg ficon
portcfg ftrace
portshow fciptunnel
portpersistentenable
Fabric OS 6.x administrator guide 427
