How to Set Up Cisco Unified IP Phones
Command or Action
Step 5
limit-dn phone-type max-lines
Example:
Router(config-cm-fallback)# limit-dn 7945 2
Step 6
exit
Example:
Router(config-cm-fallback)# exit

Configuring Cisco Unified 8941 and 8945 SCCP IP Phones

To configure Cisco Unified 8941 and 8945 SCCP IP Phones in SRST mode, perform the following
commands:
This section is required only in SRST version 8.6 and is not required for version 8.6 and higher.
Note
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
Cisco Unified SCCP and SIP SRST System Administrator Guide
88
enable
configure terminal
ephone-type phone-type
device-id number
device-type phone-type
end
Setting Up Cisco Unified IP Phones using SCCP
Purpose
(Optional) Limits the directory number lines on
Cisco IP phones during Cisco Unified CM fallback.
Note You must configure this command during initial
Cisco Unified SRST router configuration, before
any phone actually registers with the
Cisco Unified SRST router. However, you can
modify the number of lines at a later time.

For a list of available phones, see
and SIP SRST Command Reference (All
Versions).
The setting for maximum lines is from 1 to 6. The default
number of maximum directory lines is set to 6. If there is
any active phone with the last line number greater than
this limit, warning information is displayed for phone
reset.
Exits call-manager-fallback configuration mode.
Cisco SRST
OL-13143-04
